NIFE-210-E11
NEXCOM
SKU: 10725200
Industrial Fieldbus Embedded System NIFE210-E11, Intel Celeron J6413 1.8GHz, DDR4, HDMI, DP, 2x2.5GbE LAN, 1xGbE LAN, 2xCOM, 2xUSB 3.0, 4xUSB 2.0, 1x2.5" Bay, mSATA, M.2, PCIe x4, 24VDC-in
Price on request
Available
Available
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
Desktop, Wall
CPU
Processor Installed
Celeron J6413
Max CPU frequency
1.8 GHz
Drive interfaces
MicroSD
1
Ethernet
Total Ethernet
3
10/100/1000 Mbit/s
3
Interfaces
COM Total
2
RS-232/422/485
2
USB Total
6
Supported Protocols
Industrial Protocols
EtherCAT, EtherNet/IP, PROFINET, CANopen, DeviceNet, Profibus, Sercos III master
Connectors
Connectors
2xDB9, HDMI, 3xRJ45 Ethernet, 6xUSB, Display Port, DC input (terminal block)
Dimensions and weight
Width
150 mm
Depth
157 mm
Height
232 mm
System Power Input
Input Voltage DC
24..24 V
Operating Conditions
Operating Temperature
-20..80 °C
Standards and Certifications
Certifications
CE, FCC Class A
EMS
EN 61000-6-2, EN 61000-6-4
Vibration And Shock
IEC 60068-2-27, IEC 60068-2-64
Dimensions
Net Weight
1.5 kg
Gross Weight
2 kg
