DT361DM-Tactical-Tablet--M
DT Research
SKU: 80166000
6" Tactical Rugged Tablet, IP65, 1440x720, 850cd/m2, PCAP Touch, Intel Core i7-1250U CPU, 16GB LPDDR5 RAM, Up to 1TB M.2 SSD, 1xGbE LAN, 1xUSB 3.0, 1xUSB-C, WiFi/Long Range BT, Opt. (Night Vision Screen/Cam), 3100mAh Bat., 19VDC-in w/ PSU
Price on request
Available
Available
Construction
Construction Chassis
Metal Chassis with Plastic component
Protection Level of Front Side (Panel)
IP65
Protection Level of Chassis
IP65
Type
Fanless
Display
Display Type
LCD TFT
Diagonal
6 "
Maximum resolution
720x1440 Dots
Brightness
850 Cd/m2
Touch Screen
Touch Screen Type
Capacitive
CPU
СPU Generation/Family
Amber Lake Y, Alder Lake
Processor Installed
Intel Core i7-1250U
Socket
FCBGA1781
Max CPU frequency
4.7 GHz
Chipset
Chipset
Intel SoC
Memory
Form-factor
DDR5
Socket Type
Soldered
ECC
No
Default on Board Memory
16 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Total Ethernet
1
10/100/1000 Mbit/s
1
Wi-Fi
Wi-Fi Standard
802.11a/b/g/n/ac
Interfaces
USB Total
2
USB v3.x
2
Drive interfaces
M.2
1
Extension Slots
Total
1
M.2
1
M.2 Form Factor
2242 M
Antenna characteristics
Bluetooth
v5.2
LED / Controls
LED
Power LED
Controls
On/Off, Control Buttons
Connectors
Connectors
RJ45 Ethernet, 1xUSB, DC Input, USB type C
System Power Input
Input Voltage DC
19..19 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Input Voltage AC
100..240 V
Battery
Battery 1 Technology
Li-pol
Battery Capacity
3100 mA*h
Battery 1 Hotswap
Yes
Software
Operating System Compatibility
Windows 11, Windows 11 IoT Enterprise
Dimensions and weight
Width
193 mm
Height
95 mm
Depth
32 mm
Operating Conditions
Operating Temperature
0..50 °C
Humidity
5-90%
Temperature (Storage)
-40~+70
Standards and Certifications
Certifications
CE, FCC Class B, rohs
Dimensions
Net Weight
0.45 kg
Gross Weight
0.85 kg
