iTXL-H610A
GIGAIPC
SKU: 57832100
Mini-ITX Embedded Motherboard, LGA1700, Intel 13/12th Gen Core i9/i7/i5/i3/Pentium/Celeron CPU, H610 Chipset, Up to 64GB DDR4 RAM, HDMI/LVDS/DP, 2xGbE LAN, 2xSATA, 2xCOM, 4xUSB 3.2, 4xUSB 2.0 header, 2xM.2, 1x8-bit GPIO, Audio, 12-24VDC-in, 0..+60C
Price on request
Available on order
Available on order
System Architecture
Form Factor
Thin Mini-ITX
CPU
СPU Generation/Family
Alder Lake, Raptor Lake
CPU Support Type
Core i3, Core i5, Celeron, Core i7, Core i9, Pentium
Socket
LGA1700
Chipset
Chipset
Intel H610
Memory
Form-factor
DDR4
Socket Type
2xSODIMM 260-pin
ECC
No
Maximum Memory
64 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU, Intel UHD Graphics
Interfaces
DisplayPort, LVDS, HDMI
Ethernet
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
2
RS-232
1
RS-232/422/485
1
USB Total
8
USB 2.0
4
USB v3.x
4
Digital Input-Output
Channels of DIO
8
Audio
Audio Controller
Realtek ALC897
Drive interfaces
SATA 3
2
M.2
1
Extension Slots
Total
2
M.2
2
M.2 Form Factor
2280 M, 2230 E
Connectors
Connectors
HDMI, 2xRJ45 Ethernet, 4xUSB, Mic In, Line Out, DC Input, Display Port
Software
Operating System Compatibility
Windows 10, Windows 11
Dimensions and weight
Width
170 mm
Length
170 mm
Operating Conditions
Operating Temperature
0..60 °C
Humidity
0-95%
Standards and Certifications
Certifications
CE
Dimensions
Net Weight
0.48 kg
Gross Weight
0.7 kg
