AEC-6200-32
Arbor
SKU: 57866900
Fanless Embedded PC, NVIDIA Jetson AGX Orin 8-core SoC, 32GB LPDDR5 RAM, 64GB eMMC, HDMI, 2xGbE LAN, 4xGbE PoE+ LAN, 5xUSB 3.2, 2xMicro-USB, 2xCOM, 2xCAN, 16-bit DIO, 2xM.2 Key-M, 1xM.2 Key-B, 1xM.2 Key-E, 1xPCIe x8, 9-48VDC-in, -20..55C
Price on request
Available
Available
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
DIN-Rail mount, Wall
Type
Fanless
CPU
Processor Installed
Nvidia Jetson AGX Orin (8-Core)
Socket
CPU onboard
Chipset
Chipset
SoC
Memory
Form-factor
DDR5
Socket Type
Soldered
ECC
No
Default on Board Memory
32 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
NVIDIA Ampere, 1792-cores, 56 Tensor Cores
Interfaces
HDMI
Ethernet
Total Ethernet
6
10/100/1000 Mbit/s
2
PoE+ 10/100/1000 Mbit/s
4
Interfaces
COM Total
2
RS-232/422/485
2
USB Total
7
USB 2.0
2
USB v3.x
5
Digital Input-Output
Channels of DIO
16
Isolation DIO
Yes
Industrial Interfaces
CAN Port
2
Drive interfaces
M.2
2
MicroSD
1
Installed drive
Drive Type
SSD
Storage Form-Factor
eMMC
1st Storage Capacity
64 GB
Extension Slots
Total
5
PCI Express x8
1
M.2
4
M.2 Form Factor
2280 M, 2230 E, 3052 B, 3042 B
SIM Card slots
Yes, 2
Connectors
Connectors
2xDB9, HDMI, 6xRJ45 Ethernet, 5xUSB, DC input (terminal block), DIO (terminal block), CAN (terminal block), MicroSD card slot, 2xSIM Card Slot, Console Port Micro USB
System Power Input
Input Voltage DC
9..48 V
Power Supply
Supported Types of Power Supply
External power adapter AC/DC
Software
Operating System Compatibility
Linux OS
Dimensions and weight
Width
260 mm
Height
182 mm
Depth
69 mm
Operating Conditions
Operating Temperature
-25..70 °C
Humidity
5-95%
Vibration
Operating, MIL-STD-810G, Method 514.6, Procedure I, Category 4
Shock
Operating, MIL-STD-810G, Method 516.7, Procedure I
Standards and Certifications
Certifications
CE/FCC
Rolling Stock
EN 50155, EN 50121-3-2
Dimensions
Net Weight
3.8 kg
Gross Weight
4.3 kg
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
DIN-Rail mount, Wall
Type
Fanless
CPU
Processor Installed
Nvidia Jetson AGX Orin (8-Core)
Socket
CPU onboard
Chipset
Chipset
SoC
Memory
Form-factor
DDR5
Socket Type
Soldered
ECC
No
Default on Board Memory
32 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
NVIDIA Ampere, 1792-cores, 56 Tensor Cores
Interfaces
HDMI
Ethernet
Total Ethernet
6
10/100/1000 Mbit/s
2
PoE+ 10/100/1000 Mbit/s
4
Interfaces
COM Total
2
RS-232/422/485
2
USB Total
7
USB 2.0
2
USB v3.x
5
Digital Input-Output
Channels of DIO
16
Isolation DIO
Yes
Industrial Interfaces
CAN Port
2
Drive interfaces
M.2
2
MicroSD
1
Installed drive
Drive Type
SSD
Storage Form-Factor
eMMC
1st Storage Capacity
64 GB
Extension Slots
Total
5
PCI Express x8
1
M.2
4
M.2 Form Factor
2280 M, 2230 E, 3052 B, 3042 B
SIM Card slots
Yes, 2
Connectors
Connectors
2xDB9, HDMI, 6xRJ45 Ethernet, 5xUSB, DC input (terminal block), DIO (terminal block), CAN (terminal block), MicroSD card slot, 2xSIM Card Slot, Console Port Micro USB
System Power Input
Input Voltage DC
9..48 V
Power Supply
Supported Types of Power Supply
External power adapter AC/DC
Software
Operating System Compatibility
Linux OS
Dimensions and weight
Width
260 mm
Height
182 mm
Depth
69 mm
Operating Conditions
Operating Temperature
-25..70 °C
Humidity
5-95%
Vibration
Operating, MIL-STD-810G, Method 514.6, Procedure I, Category 4
Shock
Operating, MIL-STD-810G, Method 516.7, Procedure I
Standards and Certifications
Certifications
CE/FCC
Rolling Stock
EN 50155, EN 50121-3-2
Dimensions
Net Weight
3.8 kg
Gross Weight
4.3 kg
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
DIN-Rail mount, Wall
Type
Fanless
CPU
Processor Installed
Nvidia Jetson AGX Orin (8-Core)
Socket
CPU onboard
Chipset
Chipset
SoC
Memory
Form-factor
DDR5
Socket Type
Soldered
ECC
No
Default on Board Memory
32 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
NVIDIA Ampere, 1792-cores, 56 Tensor Cores
Interfaces
HDMI
Ethernet
Total Ethernet
6
10/100/1000 Mbit/s
2
PoE+ 10/100/1000 Mbit/s
4
Interfaces
COM Total
2
RS-232/422/485
2
USB Total
7
USB 2.0
2
USB v3.x
5
Digital Input-Output
Channels of DIO
16
Isolation DIO
Yes
Industrial Interfaces
CAN Port
2
Drive interfaces
M.2
2
MicroSD
1
Installed drive
Drive Type
SSD
Storage Form-Factor
eMMC
1st Storage Capacity
64 GB
Extension Slots
Total
5
PCI Express x8
1
M.2
4
M.2 Form Factor
2280 M, 2230 E, 3052 B, 3042 B
SIM Card slots
Yes, 2
Connectors
Connectors
2xDB9, HDMI, 6xRJ45 Ethernet, 5xUSB, DC input (terminal block), DIO (terminal block), CAN (terminal block), MicroSD card slot, 2xSIM Card Slot, Console Port Micro USB
System Power Input
Input Voltage DC
9..48 V
Power Supply
Supported Types of Power Supply
External power adapter AC/DC
Software
Operating System Compatibility
Linux OS
Dimensions and weight
Width
260 mm
Height
182 mm
Depth
69 mm
Operating Conditions
Operating Temperature
-25..70 °C
Humidity
5-95%
Vibration
Operating, MIL-STD-810G, Method 514.6, Procedure I, Category 4
Shock
Operating, MIL-STD-810G, Method 516.7, Procedure I
Standards and Certifications
Certifications
CE/FCC
Rolling Stock
EN 50155, EN 50121-3-2
Dimensions
Net Weight
3.8 kg
Gross Weight
4.3 kg
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
DIN-Rail mount, Wall
Type
Fanless
CPU
Processor Installed
Nvidia Jetson AGX Orin (8-Core)
Socket
CPU onboard
Chipset
Chipset
SoC
Memory
Form-factor
DDR5
Socket Type
Soldered
ECC
No
Default on Board Memory
32 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
NVIDIA Ampere, 1792-cores, 56 Tensor Cores
Interfaces
HDMI
Ethernet
Total Ethernet
6
10/100/1000 Mbit/s
2
PoE+ 10/100/1000 Mbit/s
4
Interfaces
COM Total
2
RS-232/422/485
2
USB Total
7
USB 2.0
2
USB v3.x
5
Digital Input-Output
Channels of DIO
16
Isolation DIO
Yes
Industrial Interfaces
CAN Port
2
Drive interfaces
M.2
2
MicroSD
1
Installed drive
Drive Type
SSD
Storage Form-Factor
eMMC
1st Storage Capacity
64 GB
Extension Slots
Total
5
PCI Express x8
1
M.2
4
M.2 Form Factor
2280 M, 2230 E, 3052 B, 3042 B
SIM Card slots
Yes, 2
Connectors
Connectors
2xDB9, HDMI, 6xRJ45 Ethernet, 5xUSB, DC input (terminal block), DIO (terminal block), CAN (terminal block), MicroSD card slot, 2xSIM Card Slot, Console Port Micro USB
System Power Input
Input Voltage DC
9..48 V
Power Supply
Supported Types of Power Supply
External power adapter AC/DC
Software
Operating System Compatibility
Linux OS
Dimensions and weight
Width
260 mm
Height
182 mm
Depth
69 mm
Operating Conditions
Operating Temperature
-25..70 °C
Humidity
5-95%
Vibration
Operating, MIL-STD-810G, Method 514.6, Procedure I, Category 4
Shock
Operating, MIL-STD-810G, Method 516.7, Procedure I
Standards and Certifications
Certifications
CE/FCC
Rolling Stock
EN 50155, EN 50121-3-2
Dimensions
Net Weight
3.8 kg
Gross Weight
4.3 kg
