Coeus-4002T

Coeus-4002T

NEXCOM
SKU: 80280600
Embedded Edge AI System, NVIDIA Jetson Thor T5000 14-Core CPU, 128GB LPDDR5 RAM, Blackwell 2560-Core GPU, 1TB NVMe SSD, HDMI, 5x2.5GbE LAN, 1x100GbE QSFP, 3xUSB 3.0, 1xUSB-C OTG, 1xM.2 Key-B, 1xM.2 Key-E, 2xPCIe x4, 24-30VDC-in w/ PSU
Price on request
Available
Available
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
DIN-Rail mount, Desktop, Wall
Type
Fans
CPU
Processor Installed
Nvidia Jetson T5000
Socket
CPU onboard
Max CPU frequency
2.6 GHz
Chipset
Chipset
SoC
Memory
Form-factor
DDR5
Socket Type
Soldered
ECC
Yes
Default on Board Memory
128 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
NVIDIA Blackwell, 2560-cores, 96 Tensor Cores
Interfaces
HDMI
Ethernet
Controller Type
Intel i225V
Total Ethernet
6
2,5 Gbit/s
5
SFP 100/1000 Mbit/s Ports
1
Wi-Fi
Wi-Fi Standard
Yes (Optional)
Interfaces
USB Total
4
USB v3.x
4
Drive interfaces
M.2
1
Installed drive
Drive Type
SSD
Storage Form-Factor
M.2
Drive Interface
PCIe x4
1st Storage Capacity
512 GB
Extension Slots
Total
5
PCI Express x4
2
M.2
3
M.2 Form Factor
2280 M, 2230 E, 3052 B
SIM Card slots
Yes, 1
Antenna characteristics
Cellular interfaces
4G (Optional)
LED / Controls
LED
Power LED, SSD LED
Controls
On/Off
Connectors
Connectors
HDMI, 5xRJ45 Ethernet, 3xUSB, SIM Card Slot, DC input (terminal block), USB type C, 1xSFP
System Power Input
Input Voltage DC
24..30 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Software
Operating System Compatibility
Ubuntu 24.04, NVIDIA Jetpack
Dimensions and weight
Width
268 mm
Height
75.8 mm
Depth
137 mm
Operating Conditions
Operating Temperature
-10..50 °C
Humidity
10-95%
Standards and Certifications
Certifications
CE, FCC
Safety
LVD
Dimensions
Net Weight
2.25 kg
Gross Weight
3.45 kg
