Name: AIE-KT68-1-A1
Brand: AETINA
SKU: 80405200
Price: Price on request
Availability: PreOrder

AIE-KT68-1-A1

SKU: 80405200

Embedded Edge AI PC, Nvidia Jetson Thor T4000 SoC, Blackwell 1536-Core GPU, 64GB LPDDR5x RAM, 1TB SSD, HDMI, DP, 2x10GbE, 1xGbE, 1xQSFP28 (3x25GbE), 4xUSB, 1xOTG, 2xCOM, DIO, 2xUART, 2xI2C, 2xMini-Fakra, 1xM.2 Key-B, 1xM.2 Key-E, 9-48VDC-in

Price on request

Construction

Construction Chassis

Aluminium Chassis

Mounting Configuration

Desktop, Wall

Type

Fan

CPU

Processor Installed

Nvidia Jetson T4000

Socket

CPU onboard

Max CPU frequency

2.6 GHz

Chipset

SoC

Memory

Form-factor

DDR5

Socket Type

Soldered

ECC

Default on Board Memory

64 GB

Assembly

Fixed on Board

Graphic

Graphic Controller

NVIDIA Blackwell, 1536-cores, 64 Tensor Cores

Interfaces

DisplayPort, HDMI

Ethernet

Total Ethernet

10/100/1000 Mbit/s

10 Gbit/s

Wi-Fi

Wi-Fi Standard

Yes (Optional)

Interfaces

COM Total

RS-232/422/485

USB Total

USB v3.x

Digital Input-Output

Channels of DIO

Industrial Interfaces

CAN Port

EtherCAT Port

Drive interfaces

M.2

Installed drive

Drive Type

SSD

Storage Form-Factor

M.2

Drive Interface

PCIe x4

1st Storage Capacity

1024 GB

Extension Slots

Total

M.2

M.2 Form Factor

2280 M, 2230 E, 3052 B, 3042 B

SIM Card slots

Yes, 1, Micro-SIM

Antenna characteristics

Cellular interfaces

4G (Optional), 5G (Optional)

LED / Controls

LED

Power LED, SSD LED

Controls

On/Off, 1xReset

Connectors

2xDB9, HDMI, 3xRJ45 Ethernet, 4xUSB, Mic In, Line Out, Display Port, 1xDB15 DIO, DC input (terminal block), 2xDB9 CAN, USB type C, 2xMini FAKRA, DB9 I2C, DB9 UART, 1xQSFP28

System Power Input

Input Voltage DC

9..48 V

Power Supply

Supported Types of Power Supply

External power adapter AC/DC

Software

Operating System Compatibility

Linux OS, NVIDIA Jetpack

Dimensions and weight

Width

220 mm

Height

80 mm

Depth

143 mm

Operating Conditions

Operating Temperature

-25..55 °C

Humidity

10-95%

Standards and Certifications

Certifications

CE, FCC Class A

Dimensions

Net Weight

3.17 kg

Gross Weight

3.85 kg

Documentation

AIE-KT-Datasheet.pdf
