U11I-DURABOOK-Rugged-Tablet-M
Durabook
SKU: 57325200
Rugged IP65 Tablet, 11.6" 1920x1080 300nits or 1000nits Touch Display, Intel Core i5-10210Y or i7-10510Y, 8GB RAM, 128GB SSD, 2xUSB 3.2, 1xLAN, 2MP Front /8MP Rear CAM, WiFi+BT, Bridge Battery, 4800mAh Battery or 9600mAh high capacity Windows 10 Pro
Price on request
Available on order
Available on order
Construction
Construction Chassis
Aluminium Chassis
Protection Level of Front Side (Panel)
IP65
Protection Level of Chassis
IP65
Type
Fanless
Display
Display Type
LCD
Diagonal
11.6 "
Maximum resolution
1920x1080 Dots
Brightness
1000 Cd/m2
Touch Screen
Touch Screen Type
Capacitive
CPU
Processor Installed
Intel Core i5-10210Y
Max CPU frequency
4 GHz
Memory
Form-factor
DDR3
Default on Board Memory
8 GB
Maximum Memory
16 GB
Assembly
Removable
Graphic
Interfaces
HDMI
Wi-Fi
Wi-Fi Standard
802.11a/b/g/n/ac
Interfaces
COM Total
1
RS-232
1
USB Total
2
USB v3.x
1
Audio
Audio Controller
Intel HD Audio
Drive interfaces
M.2
1
MicroSD
1
Installed drive
Drive Type
SSD
Storage Form-Factor
M.2
1st Storage Capacity
128 GB
Extension Slots
SIM Card slots
1
Additional Functions
Camera Frontside
2 MP
Rear Camera
8 MP
GPS
GPS
RFID Reader
Optional
Smart Card Reader
Optional
Fingerprint Scanner
Optional
Antenna characteristics
Cellular interfaces
2G, 4G
Bluetooth
Yes
LED / Controls
Controls
On/Off, Function Keys
Connectors
Connectors
HDMI, RJ45, SIM Card Slot, MicroSD card slot, Jack 3.5, USB type A
System Power Input
Input Voltage DC
19..19 V
Power Supply
Type of Power Supply
DC-DC
Output Power
65 W
Battery
Battery 1 Technology
Li-ion
Battery Capacity
4800 mA*h
RunTime Battery 1
0 h
Battery 1 Hotswap
Yes
Additional Battery Type
Li‑ion
Additional Battery Capacity
1100 mA*h
Software
Operating System Compatibility
Windows 10
Operating System Installed
Windows 10
Dimensions and weight
Width
317 mm
Height
215 mm
Depth
23.8 mm
Operating Conditions
Operating Temperature
-20..60 °C
Dimensions
Net Weight
1.39 kg
Gross Weight
3 kg
