RUGGEDCOM-RS900GP-M
Siemens AG
SKU: 57897400
RUGGEDCOM RS900GP Industrial Managed Layer 2 Ethernet Switch, IP40, 8x10/100BaseTX PoE ports, Optional up to 2 Fiber Ports 100/1000Base-X or 10/100/1000Base-TX LC/SC/ST/SFP, 1xCOM, 54VDC-in, Wide Temp. -40..85C
Price on request
Available
Available
Ethernet
10/100/1000 Mbit/s
8
SFP 100/1000 Mbit/s Ports
2
Switch Properties
MAC Table Size
32000
Max. Number of VLANs
255
IGMP Groups
256
Supported Protocols
Managment Protocols
SNMPv1/v2c/v3, HTTP, LLDP, SNTP, TFTP, DHCP Client, IGMP Snooping v1/v2/v3, IGMP Querier, SFTP, DHCP Option 82
Reservation protocols
RSTP, STP
Security Protocols
HTTPS, SSH, SSL, TACACS+
IEEE Standard
IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3ad for Port Trunk with LACP, EE 802.3af for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX
System Power Input
Input Voltage DC
45..57 V
Construction
Mounting Configuration
DIN-Rail mount
Protection Level of Chassis
IP40
Dimensions and weight
Width
90 mm
Depth
176.5 mm
Height
154.4 mm
Operating Conditions
Operating Temperature
-40..85 °C
Humidity
5-95%
Standards and Certifications
EMI
EN 55022, FCC Part 15 Subpart B Class A
Vibration And Shock
IEC 61850-3
Dimensions
Net Weight
2.2 kg
Gross Weight
3 kg
Ethernet
10/100/1000 Mbit/s
