IGS-4215-16P2T2S

IGS-4215-16P2T2S

Planet
SKU: 57883400
Industrial Managed Ethernet Switch IP30 18-Port 10/100/1000BASE-T with 16-port PoE+, 2- Port 1000BASE-SX/LX/BX SFP, 1xCOM, 2xDI, 2xDO, 48..54VDC, -40..75C Operating Temperature
Price on request
Available
Available

Ethernet
10/100/1000 Mbit/s
18
SFP 1000 Mbit Ports
2
PoE 10/100/1000 Mbit/s
16
Switch Properties
Jumbo Frame Size
10 kB
Max. Number of VLANs
256
Supported Protocols
Managment Protocols
SMTP, SNMPv1/v2c/v3, HTTP, Syslog, Telnet, NTP, LACP, IGMP Snooping v1/v2/v3, IGMP Querier
Reservation protocols
ERPS, RSTP, STP
Security Protocols
RADIUS, TACACS+
IEEE Standard
IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, IEEE 802.3ad for Port Trunk with LACP, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802.3az for Energy-Efficient Ethernet
System Power Input
Input Voltage DC
48..54 V
Dimensions and weight
Width
76 mm
Depth
135 mm
Height
152 mm
Operating Conditions
Operating Temperature
-40..75 °C
Humidity
5-95%
Standards and Certifications
Certifications
CE, FCC Class A
Freefall
IEC 60068-2-32
Vibration And Shock
IEC 60068-2-6, IEC 60068-2-27
Dimensions
Net Weight
1.4 kg
Gross Weight
1.9 kg
