MEGA-3110

Arestech
SKU: 57571600
High-Performance GPU Computer, Intel 8th/9th Gen Core i3/i5/i7 CPU, VGA, DVI-D, DP, 3xGbE, 6xUSB 3.2, 6xRS232/422/485, 2x mSATA, 4x2.5" SATA Bay, 9..48VDC, -40..60C operating temp
Price on request
Available
Available

Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
Wall
Type
Fanless
CPU
СPU Generation/Family
Coffee Lake
Socket
LGA1151
Memory
Maximum Memory
32 GB
Graphic
Graphic Controller
Intel UHD Graphics 630
Ethernet
Controller Type
Intel i210-AT, Intel i219-LM
10/100/1000 Mbit/s
3
Interfaces
COM Total
6
RS-232/422/485
6
USB Total
6
Digital Input-Output
GPIO
8xDigital In / 8xDigital Out
Storage Cage
Number Of Cage External
4
2.5" Cage External
2
2.5" Cage Intenal
2
Connectors
Connectors
6xDB9, DVI-D, DB15 VGA, 3xRJ45, 6xUSB, Mic In, Line Out, Display Port
System Power Input
Power Consumption
1008 W
Dimensions and weight
Width
356 mm
Height
168 mm
Depth
241.5 mm
Operating Conditions
Vibration
3 Grms, 5-500 Hz, 3 Axis
Shock
30 Grms, Half-sine 11 ms
Standards and Certifications
Certifications
CE, FCC
Dimensions
Gross Weight
9 kg
