Name: iROBO-SR102-v3
Brand: Industrial Personal Computer 2U GmbH
SKU: 56088900
Price: 533.23 EUR
Availability: Discontinued

Home

Catalog

Industrial Computers

19" Industrial Сomputers

Industrial Rack Servers

iROBO-SR102-v3

Industrial Personal Computer 2U GmbH

SKU: 56088900

Mini Tower Server, 1x Intel CPU E3-1200 v3/v4/ Core i3 4th Gen. LGA 1150, max. 32GB DDR3 ECC RAM, VGA, 2xGbit LAN, IPMI 2.0, 300W 80 Plus Bronze PSU

End-of-life product

Construction

Mounting Configuration

19" Rackmount

Type

Fans

CPU

Socket

LGA1150

CPU Support Type

Core i3, Celeron, Pentium, Xeon

Number of CPU

Chipset

Intel C224

Memory

Form-factor

DDR3

Socket Type

4xDIMM

ECC

Yes

Maximum Memory

32 GB

Assembly

Removable

Ethernet

Controller Type

Intel i217LM 10/100/1000 Mbps, Intel i210-AT, Realtek RTL8211E

Total Ethernet

10/100/1000 Mbit/s

Interfaces

COM Total

USB Total

USB 2.0

Storage Cage

3.5" Cage Intenal

LED / Controls

LED

1xHDD LED, Power LED, LAN LED

Connectors

DB9, DB15 VGA, 3xRJ45, 4xUSB

Power Supply

Output Power

400 W

Input Voltage AC

100..240 V

Dimensions and weight

Width

437 mm

Height

43 mm

Depth

369 mm

Operating Conditions

Operating Temperature

5..35 °C

Standards and Certifications

Certifications

Dimensions

Gross Weight

14 kg
