HBJC903I36-6412P42

HBJC903I36-6412P42

JetWay
SKU: 57935400
Fanless Embedded PC, Intel Celeron J6412 2.0GHz CPU, Up to 32GB DDR4 RAM, HDMI, 2x2.5GbE LAN, 4x2.5GbE PoE LAN, 1xRJ45 COM, 3xCOM, 2xUSB 3.2, 2.5" Drive Bay, 1xM.2 2242 Key-M, TPM 2.0, 12VDC-in w/ 90W PSU, 9-36V PoE DC-in mode, -10..50C
Price on request
Available
Available

Construction
Construction Chassis
Metal Chassis
Mounting Configuration
Desktop, Wall
Type
Fanless
CPU
СPU Generation/Family
Elkhart Lake
Processor Installed
Intel Celeron J6412
Socket
CPU onboard
Max CPU frequency
2.6 GHz
Memory
Form-factor
DDR4
Maximum Memory
32 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Interfaces
HDMI
Ethernet
Controller Type
Intel i225V, Intel i226V
2,5 Gbit/s
2
PoE 10/100/1000 Mbit/s
4
Interfaces
COM Total
4
RS-232/422/485
1
USB Total
2
USB v3.x
2
Drive interfaces
SATA 3
1
M.2
1
Storage Cage
2.5" Cage Intenal
1
Extension Slots
Total
1
M.2
1
M.2 Form Factor
2242 M
LED / Controls
Controls
On/Off
Connectors
Connectors
3xDB9, HDMI, 6xRJ45 Ethernet, 2xUSB, Console Port RS-232 (RJ-45), DC input (terminal block)
System Power Input
Input Voltage DC
12 V
Backup input DC supply voltage
9~36 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Output Power
90 W
Software
Operating System Compatibility
Linux OS, Windows 10, Windows 11
Dimensions and weight
Width
200 mm
Height
59.5 mm
Depth
180.4 mm
Operating Conditions
Operating Temperature
-10..50 °C
Standards and Certifications
Certifications
CE/FCC
Safety
LVD
Dimensions
Net Weight
2.27 kg
Gross Weight
3.27 kg
Construction
Construction Chassis
