ET2-0602-M

ET2-0602-M

Leonton
SKU: 80025100
Industrial Ethernet Switch, IP30, 4x10/100Base-TX, 2x100Base-FX SC Connector, Multi-mode, 2km/1310nm, Dual 12..48VDC, Operating Temperature -10..65 C
Price on request
Available
Available

Ethernet
Total Ethernet
4
10/100 Mbit/s
4
Fiber
Number of Optical Ports
2xSC
Type of Fibre Optic
multi-mode
Transmission Range
2 km
Length Wave RX/TX
1310 nm
Switch Properties
MAC Table Size
2000
Supported Protocols
IEEE Standard
IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control
System Power Input
Input Voltage DC
12..48 V
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
DIN-Rail mount, Wall
Protection Level of Chassis
IP30
Dimensions and weight
Width
30 mm
Depth
142 mm
Height
99 mm
Operating Conditions
Operating Temperature
-10..65 °C
Humidity
5-95%
Standards and Certifications
EMI
FCC Part 15 Subpart B Class A
EMS
IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 55032, EN 55035
Safety
UL 61010-2-201
Freefall
IEC 60068-2-32
Vibration And Shock
IEC 60068-2-6, IEC 60068-2-27
Dimensions
Net Weight
0.62 kg
Gross Weight
1.2 kg
