cMT-SVRiv5
Weintek
SKU: 06515400
CloudHMI capacitive touch screen and CloudHMI server
Price on request
Available
Available
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
Panel
Protection Level of Chassis
IP65
Display
Display Type
LCD TFT
Diagonal
9.7 "
Maximum resolution
1024x768 Dots
Brightness
350 Cd/m2
Contrast Ratio
500~1
Touch Screen
Touch Screen Type
Capacitive
Memory
Default on Board Memory
1 GB
Installed drive
Flash Memory Capacity
512 MB
Ethernet
10/100/1000 Mbit/s
1
Interfaces
COM Total
3
RS-232
1
RS-485
2
USB Total
1
Software
Development Software
EasyBuilder Pro
Operating System Installed
Special
System Power Input
Input Voltage DC
24..24 V
Dimensions and weight
Width
257 mm
Depth
33 mm
Height
200 mm
Operating Conditions
Operating Temperature
-20..50 °C
Standards and Certifications
Certifications
CE
Safety
cUL
Dimensions
Gross Weight
0.3 kg
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
Panel
Protection Level of Chassis
IP65
Display
Display Type
LCD TFT
Diagonal
9.7 "
Maximum resolution
1024x768 Dots
Brightness
350 Cd/m2
Contrast Ratio
500~1
Touch Screen
Touch Screen Type
Capacitive
Memory
Default on Board Memory
1 GB
Installed drive
Flash Memory Capacity
512 MB
Ethernet
10/100/1000 Mbit/s
1
Interfaces
COM Total
3
RS-232
1
RS-485
2
USB Total
1
Software
Development Software
EasyBuilder Pro
Operating System Installed
Special
System Power Input
Input Voltage DC
24..24 V
Dimensions and weight
Width
257 mm
Depth
33 mm
Height
200 mm
Operating Conditions
Operating Temperature
-20..50 °C
Standards and Certifications
Certifications
CE
Safety
cUL
Dimensions
Gross Weight
0.3 kg
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
Panel
Protection Level of Chassis
IP65
Display
Display Type
LCD TFT
Diagonal
9.7 "
Maximum resolution
1024x768 Dots
Brightness
350 Cd/m2
Contrast Ratio
500~1
Touch Screen
Touch Screen Type
Capacitive
Memory
Default on Board Memory
1 GB
Installed drive
Flash Memory Capacity
512 MB
Ethernet
10/100/1000 Mbit/s
1
Interfaces
COM Total
3
RS-232
1
RS-485
2
USB Total
1
Software
Development Software
EasyBuilder Pro
Operating System Installed
Special
System Power Input
Input Voltage DC
24..24 V
Dimensions and weight
Width
257 mm
Depth
33 mm
Height
200 mm
Operating Conditions
Operating Temperature
-20..50 °C
Standards and Certifications
Certifications
CE
Safety
cUL
Dimensions
Gross Weight
0.3 kg
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
Panel
Protection Level of Chassis
IP65
Display
Display Type
LCD TFT
Diagonal
9.7 "
Maximum resolution
1024x768 Dots
Brightness
350 Cd/m2
Contrast Ratio
500~1
Touch Screen
Touch Screen Type
Capacitive
Memory
Default on Board Memory
1 GB
Installed drive
Flash Memory Capacity
512 MB
Ethernet
10/100/1000 Mbit/s
1
Interfaces
COM Total
3
RS-232
1
RS-485
2
USB Total
1
Software
Development Software
EasyBuilder Pro
Operating System Installed
Special
System Power Input
Input Voltage DC
24..24 V
Dimensions and weight
Width
257 mm
Depth
33 mm
Height
200 mm
Operating Conditions
Operating Temperature
-20..50 °C
Standards and Certifications
Certifications
CE
Safety
cUL
Dimensions
Gross Weight
0.3 kg
Software
Software
Software
Software
Weintek
cMT-SVR-102 Cloud HMI, ARM Cortex A8 600MHz, 1024x748, 256MB RAM, 256MB Flash, real time clock, Com1: RS-232, Com2: RS-485 2w/4w, Com3: RS-485 2w, EasyAccess 2.0, 24VDC-in
Weintek
cMT-SVR-200 Cloud HMI, 32-bit RISC 600 MHz, 1024x748, 256MB RAM, 256MB Flash, real time clock, Wi-Fi, Com1: RS-232, Com2: RS-485 2w/4w, Com3: RS-485 2w
Weintek
cMT-SVR-202 Cloud HMI, 32-bit RISC 600 MHz, 1024x748, 256MB RAM, 256MB Flash, real time clock, Wi-Fi, Com1: RS-232, Com2: RS-485 2w/4w, Com3: RS-485 2w, EasyAccess 2.0
