BEDROCK-PC-R8000-R8X60
SolidRun
SKU: 80065900
DIN-Rail Bedrock R8000 PC, AMD Ryzen 8000 Series CPU, 60W TDP, Up to 96GB DDR5 RAM, HDMI+USB4 or HDMI/DP/2xMiniDP, Up to 4x2.5GbE LAN, 4xUSB 3.2, Up to 5xM.2 (3xKey-M NVME/Hailo, 1xKey-E WiFi+BT/Hailo, 1xKey-B LTE), Up to 12-60VDC-in w/ Power Module
Price on request
Available on order
Available on order
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
DIN-Rail mount, Desktop, Wall
Type
Fanless
CPU
СPU Generation/Family
Zen 4 Hawk Point
Socket
CPU onboard
CPU Support Type
Ryzen 7, Ryzen 9
Chipset
Chipset
SoC
Memory
Form-factor
DDR5
Socket Type
2xSODIMM
ECC
Yes
Maximum Memory
96 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Interfaces
DisplayPort, HDMI, 2x Mini DP
Ethernet
Controller Type
Intel i226
Total Ethernet
2
2,5 Gbit/s
2
Interfaces
USB Total
5
USB 2.0
1
USB v3.x
4
Drive interfaces
M.2
3
Extension Slots
Total
5
M.2
5
M.2 Form Factor
2242 M, 2280 M, 2230 E, 3052 B, 3042 B
SIM Card slots
Yes, 2, Nano SIM
Antenna characteristics
Cellular interfaces
4G (Optional)
LED / Controls
LED
Power LED, WLAN LED, SSD LED
Controls
On/Off
Connectors
Connectors
HDMI, 2xRJ45 Ethernet, 4xUSB, Display Port, 1xMini USB, DC input (terminal block), 2xMini DisplayPort
System Power Input
Input Voltage DC
12..60 V
Power Supply
Supported Types of Power Supply
External power adapter AC/DC
Software
Operating System Compatibility
Linux OS, Windows 10 IoT Enterprise, Windows 10, Windows 11, Windows 11 IoT Enterprise
Dimensions and weight
Width
160 mm
Height
73 mm
Depth
130 mm
Operating Conditions
Operating Temperature
-40..85 °C
Humidity
10-90%
Dimensions
Net Weight
2 kg
Gross Weight
2.4 kg
