AIGE-1000-C10

AIGE-1000-C10

NEXCOM
SKU: 80048000
Embedded Edge AI Server, Intel 14/13/12th Gen Core i9/i7/i5/i3 CPU, Q670E Chipset, Up to 64GB LPDDR5 RAM, 2xHDMI, 2xDP, 2x2.5GbE LAN, 8xUSB 3.2, 2x2.5" Bay, 1xMiniPCIe, 1xM.2 2280 Key-M, 1xM.2 3042/3052 Key-B, 1xPCIe x16, 850W PSU, 100-240VAC-in
Price on request
Available
Available

Construction
Construction Chassis
Metal Chassis
Mounting Configuration
Embedded, Desktop
Type
Fan
CPU
СPU Generation/Family
Alder Lake, Raptor Lake
Processor Installed
Options Available – Contact Sales
Socket
LGA1700
CPU Support Type
Core i3, Core i5, Core i7, Core i9
Chipset
Chipset
Intel Q670E
Memory
Form-factor
DDR5
Socket Type
2xSODIMM
ECC
No
Maximum Memory
64 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Interfaces
2xHDMI, 2xDisplayPort
Ethernet
Controller Type
Intel i226-IT
Total Ethernet
2
2,5 Gbit/s
2
Interfaces
COM Total
2
RS-232/422/485
2
USB Total
8
USB v3.x
8
Drive interfaces
SATA 3
2
RAID Levels
0, 1
M.2
1
mSATA
1
Storage Cage
Number Of Cage External
2
2.5" Cage Intenal
2
Extension Slots
Total
4
PCI Express x16
1
M.2
2
M.2 Form Factor
2280 M, 3052 B, 3042 B, 2242 B
Mini-PCIe/Mini Card
1
SIM Card slots
Yes, 1, Nano SIM
LED / Controls
LED
COM-ports LED
Controls
On/Off
Connectors
Connectors
2xHDMI, 2xRJ45 Ethernet, 8xUSB, AC Input, 2xDisplayPort
Power Supply
Type of Power Supply
Flex ATX
Output Power
850 W
Input Voltage AC
100..240 V
Software
Operating System Compatibility
Linux OS, Windows 10 IoT Enterprise, Windows 10, Windows 11, Windows 11 IoT Enterprise
Dimensions and weight
Width
179 mm
Height
261 mm
Depth
426 mm
Operating Conditions
Operating Temperature
-5..55 °C
Standards and Certifications
Certifications
CE, FCC Class A, EN61000-6-2, EN61000-6-4
Dimensions
Net Weight
3.2 kg
Gross Weight
3.8 kg
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
Embedded, Desktop
Type
Fan
CPU
СPU Generation/Family
Alder Lake, Raptor Lake
Processor Installed
Options Available – Contact Sales
Socket
LGA1700
CPU Support Type
Core i3, Core i5, Core i7, Core i9
Chipset
Chipset
Intel Q670E
Memory
Form-factor
DDR5
Socket Type
2xSODIMM
ECC
No
Maximum Memory
64 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Interfaces
2xHDMI, 2xDisplayPort
Ethernet
Controller Type
Intel i226-IT
Total Ethernet
2
2,5 Gbit/s
2
Interfaces
COM Total
2
RS-232/422/485
2
USB Total
8
USB v3.x
8
Drive interfaces
SATA 3
2
RAID Levels
0, 1
M.2
1
mSATA
1
Storage Cage
Number Of Cage External
2
2.5" Cage Intenal
2
Extension Slots
Total
4
PCI Express x16
1
M.2
2
M.2 Form Factor
2280 M, 3052 B, 3042 B, 2242 B
Mini-PCIe/Mini Card
1
SIM Card slots
Yes, 1, Nano SIM
LED / Controls
LED
COM-ports LED
Controls
On/Off
Connectors
Connectors
2xHDMI, 2xRJ45 Ethernet, 8xUSB, AC Input, 2xDisplayPort
Power Supply
Type of Power Supply
Flex ATX
Output Power
850 W
Input Voltage AC
100..240 V
Software
Operating System Compatibility
Linux OS, Windows 10 IoT Enterprise, Windows 10, Windows 11, Windows 11 IoT Enterprise
Dimensions and weight
Width
179 mm
Height
261 mm
Depth
426 mm
Operating Conditions
Operating Temperature
-5..55 °C
Standards and Certifications
Certifications
CE, FCC Class A, EN61000-6-2, EN61000-6-4
Dimensions
Net Weight
3.2 kg
Gross Weight
3.8 kg
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
Embedded, Desktop
Type
Fan
CPU
СPU Generation/Family
Alder Lake, Raptor Lake
Processor Installed
Options Available – Contact Sales
Socket
LGA1700
CPU Support Type
Core i3, Core i5, Core i7, Core i9
Chipset
Chipset
Intel Q670E
Memory
Form-factor
DDR5
Socket Type
2xSODIMM
ECC
No
Maximum Memory
64 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Interfaces
2xHDMI, 2xDisplayPort
Ethernet
Controller Type
Intel i226-IT
Total Ethernet
2
2,5 Gbit/s
2
Interfaces
COM Total
2
RS-232/422/485
2
USB Total
8
USB v3.x
8
Drive interfaces
SATA 3
2
RAID Levels
0, 1
M.2
1
mSATA
1
Storage Cage
Number Of Cage External
2
2.5" Cage Intenal
2
Extension Slots
Total
4
PCI Express x16
1
M.2
2
M.2 Form Factor
2280 M, 3052 B, 3042 B, 2242 B
Mini-PCIe/Mini Card
1
SIM Card slots
Yes, 1, Nano SIM
LED / Controls
LED
COM-ports LED
Controls
On/Off
Connectors
Connectors
2xHDMI, 2xRJ45 Ethernet, 8xUSB, AC Input, 2xDisplayPort
Power Supply
Type of Power Supply
Flex ATX
Output Power
850 W
Input Voltage AC
100..240 V
Software
Operating System Compatibility
Linux OS, Windows 10 IoT Enterprise, Windows 10, Windows 11, Windows 11 IoT Enterprise
Dimensions and weight
Width
179 mm
Height
261 mm
Depth
426 mm
Operating Conditions
Operating Temperature
-5..55 °C
Standards and Certifications
Certifications
CE, FCC Class A, EN61000-6-2, EN61000-6-4
Dimensions
Net Weight
3.2 kg
Gross Weight
3.8 kg
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
Embedded, Desktop
Type
Fan
CPU
СPU Generation/Family
Alder Lake, Raptor Lake
Processor Installed
Options Available – Contact Sales
Socket
LGA1700
CPU Support Type
Core i3, Core i5, Core i7, Core i9
Chipset
Chipset
Intel Q670E
Memory
Form-factor
DDR5
Socket Type
2xSODIMM
ECC
No
Maximum Memory
64 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Interfaces
2xHDMI, 2xDisplayPort
Ethernet
Controller Type
Intel i226-IT
Total Ethernet
2
2,5 Gbit/s
2
Interfaces
COM Total
2
RS-232/422/485
2
USB Total
8
USB v3.x
8
Drive interfaces
SATA 3
2
RAID Levels
0, 1
M.2
1
mSATA
1
Storage Cage
Number Of Cage External
2
2.5" Cage Intenal
2
Extension Slots
Total
4
PCI Express x16
1
M.2
2
M.2 Form Factor
2280 M, 3052 B, 3042 B, 2242 B
Mini-PCIe/Mini Card
1
SIM Card slots
Yes, 1, Nano SIM
LED / Controls
LED
COM-ports LED
Controls
On/Off
Connectors
Connectors
2xHDMI, 2xRJ45 Ethernet, 8xUSB, AC Input, 2xDisplayPort
Power Supply
Type of Power Supply
Flex ATX
Output Power
850 W
Input Voltage AC
100..240 V
Software
Operating System Compatibility
Linux OS, Windows 10 IoT Enterprise, Windows 10, Windows 11, Windows 11 IoT Enterprise
Dimensions and weight
Width
179 mm
Height
261 mm
Depth
426 mm
Operating Conditions
Operating Temperature
-5..55 °C
Standards and Certifications
Certifications
CE, FCC Class A, EN61000-6-2, EN61000-6-4
Dimensions
Net Weight
3.2 kg
Gross Weight
3.8 kg

Documentation
AIGE-1000-C10-Datasheet.pdf
Documentation
AIGE-1000-C10-Datasheet.pdf
Documentation
AIGE-1000-C10-Datasheet.pdf
Documentation
AIGE-1000-C10-Datasheet.pdf
