NISE-51

NISE-51

NEXCOM
SKU: 08505600
Fanless Embedded System, Intel Celeron N3350 2.4GHz, DDR3L, 16GB eMMC on-board, HDMI, 2xGbit LAN, 2x RS232, 1x RS422/485, 4xUSB2.0, 3x Mini-PCIe, 24V DC-In, without Power Adapter
Price on request
Available
Available

Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
Embedded, Desktop, Wall
Type
Fanless
CPU
Processor Installed
Intel Celeron N3350
Max CPU frequency
2.4 GHz
Memory
Form-factor
DDR3L
Socket Type
1xSODIMM
ECC
No
Maximum Memory
8 GB
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Controller Type
Intel i210-AT
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
4
RS-232
3
RS-422/485
1
USB Total
4
USB 2.0
2
USB v3.x
2
Digital Input-Output
GPIO
4xDigital In / 4xDigital Out
Audio
Audio Controller
Intel HD Audio
Installed drive
Drive Type
SSD
1st Storage Capacity
16 GB
Extension Slots
Total
3
M.2
2
Mini-PCIe/Mini Card
1
SIM Card slots
1
Connectors
Connectors
3xDB9, 2xRJ45, 4xUSB, Line Out, DC Input, Display Port, SIM Card Slot
System Power Input
Input Voltage DC
24..24 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Output Power
60 W
Software
Operating System Compatibility
Windows 10 IoT Enterprise, Linux kernel 4.x
Dimensions and weight
Width
162 mm
Height
26 mm
Depth
150 mm
Operating Conditions
Operating Temperature
-5..55 °C
Vibration
2Grms @ 5~500 Hz
Shock
50G
Standards and Certifications
Certifications
CE, FCC Class A
Vibration And Shock
IEC 60068-2-6, IEC 60068-2-64
Dimensions
Net Weight
0.85 kg
Gross Weight
1.4 kg
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
Embedded, Desktop, Wall
Type
Fanless
CPU
Processor Installed
Intel Celeron N3350
Max CPU frequency
2.4 GHz
Memory
Form-factor
DDR3L
Socket Type
1xSODIMM
ECC
No
Maximum Memory
8 GB
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Controller Type
Intel i210-AT
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
4
RS-232
3
RS-422/485
1
USB Total
4
USB 2.0
2
USB v3.x
2
Digital Input-Output
GPIO
4xDigital In / 4xDigital Out
Audio
Audio Controller
Intel HD Audio
Installed drive
Drive Type
SSD
1st Storage Capacity
16 GB
Extension Slots
Total
3
M.2
2
Mini-PCIe/Mini Card
1
SIM Card slots
1
Connectors
Connectors
3xDB9, 2xRJ45, 4xUSB, Line Out, DC Input, Display Port, SIM Card Slot
System Power Input
Input Voltage DC
24..24 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Output Power
60 W
Software
Operating System Compatibility
Windows 10 IoT Enterprise, Linux kernel 4.x
Dimensions and weight
Width
162 mm
Height
26 mm
Depth
150 mm
Operating Conditions
Operating Temperature
-5..55 °C
Vibration
2Grms @ 5~500 Hz
Shock
50G
Standards and Certifications
Certifications
CE, FCC Class A
Vibration And Shock
IEC 60068-2-6, IEC 60068-2-64
Dimensions
Net Weight
0.85 kg
Gross Weight
1.4 kg
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
Embedded, Desktop, Wall
Type
Fanless
CPU
Processor Installed
Intel Celeron N3350
Max CPU frequency
2.4 GHz
Memory
Form-factor
DDR3L
Socket Type
1xSODIMM
ECC
No
Maximum Memory
8 GB
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Controller Type
Intel i210-AT
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
4
RS-232
3
RS-422/485
1
USB Total
4
USB 2.0
2
USB v3.x
2
Digital Input-Output
GPIO
4xDigital In / 4xDigital Out
Audio
Audio Controller
Intel HD Audio
Installed drive
Drive Type
SSD
1st Storage Capacity
16 GB
Extension Slots
Total
3
M.2
2
Mini-PCIe/Mini Card
1
SIM Card slots
1
Connectors
Connectors
3xDB9, 2xRJ45, 4xUSB, Line Out, DC Input, Display Port, SIM Card Slot
System Power Input
Input Voltage DC
24..24 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Output Power
60 W
Software
Operating System Compatibility
Windows 10 IoT Enterprise, Linux kernel 4.x
Dimensions and weight
Width
162 mm
Height
26 mm
Depth
150 mm
Operating Conditions
Operating Temperature
-5..55 °C
Vibration
2Grms @ 5~500 Hz
Shock
50G
Standards and Certifications
Certifications
CE, FCC Class A
Vibration And Shock
IEC 60068-2-6, IEC 60068-2-64
Dimensions
Net Weight
0.85 kg
Gross Weight
1.4 kg
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
Embedded, Desktop, Wall
Type
Fanless
CPU
Processor Installed
Intel Celeron N3350
Max CPU frequency
2.4 GHz
Memory
Form-factor
DDR3L
Socket Type
1xSODIMM
ECC
No
Maximum Memory
8 GB
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Controller Type
Intel i210-AT
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
4
RS-232
3
RS-422/485
1
USB Total
4
USB 2.0
2
USB v3.x
2
Digital Input-Output
GPIO
4xDigital In / 4xDigital Out
Audio
Audio Controller
Intel HD Audio
Installed drive
Drive Type
SSD
1st Storage Capacity
16 GB
Extension Slots
Total
3
M.2
2
Mini-PCIe/Mini Card
1
SIM Card slots
1
Connectors
Connectors
3xDB9, 2xRJ45, 4xUSB, Line Out, DC Input, Display Port, SIM Card Slot
System Power Input
Input Voltage DC
24..24 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Output Power
60 W
Software
Operating System Compatibility
Windows 10 IoT Enterprise, Linux kernel 4.x
Dimensions and weight
Width
162 mm
Height
26 mm
Depth
150 mm
Operating Conditions
Operating Temperature
-5..55 °C
Vibration
2Grms @ 5~500 Hz
Shock
50G
Standards and Certifications
Certifications
CE, FCC Class A
Vibration And Shock
IEC 60068-2-6, IEC 60068-2-64
Dimensions
Net Weight
0.85 kg
Gross Weight
1.4 kg

Documentation
NISE-51-Datasheet-07172023.pdf NISE-51-User-Manual-August-2021.pdf
Documentation
NISE-51-Datasheet-07172023.pdf NISE-51-User-Manual-August-2021.pdf
Documentation
NISE-51-Datasheet-07172023.pdf NISE-51-User-Manual-August-2021.pdf
Documentation
NISE-51-Datasheet-07172023.pdf NISE-51-User-Manual-August-2021.pdf
