*EOL* Fanless Embedded Server, support 3rd gen. Intel Core i3/i5 CPU, up to 8GB DDR3 RAM, VGA, DVI-D, 2xDisplay Port, 2xGbE LAN, 6xUSB, 6xCOM, Audio, CFast Socket, 2.5" SATA HDD Bay, Mini-PCIe, 2xPCIe x4, 9..30V DC-In
NISE-3600E2
NEXCOM
SKU: 55520400
Price on request
Available on order
Available on order
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
Desktop, Wall
Type
Fanless
CPU
CPU Support Type
Core i3, Core i5, Celeron
Chipset
Chipset
Intel QM77
Memory
Form-factor
DDR3
ECC
No
Maximum Memory
8 GB
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Controller Type
Intel 82574L 10/100/1000 Mbps, Intel 82579LM 10/100/1000Mbps
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
6
RS-232
5
RS-232/422/485
1
USB Total
6
USB 2.0
2
USB v3.x
4
Drive interfaces
CFast Slots
1
Storage Cage
Number Of Cage External
1
2.5" Cage Intenal
1
Extension Slots
Total
3
PCI Express x4
2
Mini-PCIe/Mini Card
1
SIM Card slots
1
Connectors
Connectors
2xDB9, DB44, DVI-D, DB15 VGA, 2xRJ45, 6xUSB, Mic In, Line Out, DC Input, 2xDisplayPort
System Power Input
Input Voltage DC
9..30 V
Dimensions and weight
Width
215 mm
Height
114 mm
Depth
272 mm
Operating Conditions
Operating Temperature
-5..55 °C
Vibration
Random: 0.5Grms @ 5~500 Hz
Shock
HDD: 20G, half sine, 11ms
Standards and Certifications
Certifications
CE, FCC Class A
Safety
UL/cUL
Dimensions
Gross Weight
7.02 kg
