Industrial Computers
Embedded Edge PC, Industrial Box / Mini-PC
Embedded Industrial Edge Computer
NISE-2410-J1900

NISE-2410-J1900

NEXCOM
SKU: 06876400
By request (MOQ), Embedded System NISE-2410-J1900, Intel Celeron J1900 2GHz, DDR3L RAM up to 8GB, DVI-I, HDMI, 2xGbit LAN, 4xCOM, 5xUSB, SIM card holder, GPIO, Audio, 2.5" HDD Bay, CFast, 2xMini-PCIe, PCI, 9..30V DC-In
Price on request
Available
Available

Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
Desktop, Wall
Type
Fanless
CPU
СPU Generation/Family
Bay Trail
Processor Installed
Intel Celeron J1900
Socket
FCBGA1170
Max CPU frequency
2.42 GHz
Chipset
Chipset
Intel SoC
Memory
Form-factor
DDR3L
Socket Type
2xSODIMM
ECC
No
Maximum Memory
8 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Interfaces
DVI-I, HDMI
Ethernet
Controller Type
Intel i210-IT
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
4
RS-232
2
RS-232/422/485
2
USB Total
5
USB 2.0
4
USB v3.x
1
Digital Input-Output
GPIO
4xDigital In / 4xDigital Out
Drive interfaces
mSATA
1
CFast Slots
1
Storage Cage
Number Of Cage External
1
2.5" Cage Intenal
1
Extension Slots
Total
3
PCI
1
Mini-PCIe/Mini Card
2
SIM Card slots
Yes, 1
LED / Controls
LED
Power LED, LAN LED, SSD LED
Controls
On/Off
Connectors
Connectors
4xDB9, DVI-I, HDMI, 2xRJ45 Ethernet, 5xUSB, Mic In, Line Out, SIM Card Slot, DC input (terminal block), CFast slot
System Power Input
Input Voltage DC
9..30 V
Power Supply
Supported Types of Power Supply
External power adapter AC/DC
Software
Operating System Compatibility
Linux OS, Windows 10 IoT Enterprise, Windows 10
Dimensions and weight
Width
195 mm
Height
90 mm
Depth
200 mm
Operating Conditions
Operating Temperature
-5..55 °C
Humidity
10-95%
Vibration
Random: 0.5Grms @ 5~500 Hz
Shock
HDD: 20G, half sine, 11ms
Standards and Certifications
Certifications
CE, FCC Class A
Vibration And Shock
IEC 60068-2-6, IEC 60068-2-27, IEC 60068-2-64
Dimensions
Net Weight
3.6 kg
Gross Weight
4 kg
