NISE-108-J3455E
NEXCOM
SKU: 57000900
Fanless Mini PC NISE108, Intel Celeron J3455 1.5GHz, up to 8GB DDR3L RAM, 2xDP, 2xGbE LAN, 3xCOM, 4xUSB, 2.5" SATA HDD Drive Bay, M.2 2242 Key B (SATA), 1xMiniPCIe, 24V DC-In, without power adapter
Price on request
Available
Available
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
Desktop, Wall
Type
Fanless
CPU
Processor Installed
Intel Celeron J3455
Max CPU frequency
2.3 GHz
Memory
Form-factor
DDR3L
Socket Type
1xSODIMM
Maximum Memory
8 GB
Ethernet
Controller Type
Intel i210-AT
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
3
RS-232
2
RS-232/422/485
1
USB Total
4
USB 2.0
2
USB v3.x
2
Storage Cage
Number Of Cage External
1
2.5" Cage Intenal
1
Extension Slots
M.2
1
Mini-PCIe/Mini Card
1
Connectors
Connectors
3xDB9, 2xRJ45, 4xUSB, 2xDisplayPort, DC input (terminal block)
System Power Input
Input Voltage DC
24..24 V
Dimensions and weight
Width
185 mm
Height
54 mm
Depth
131 mm
Operating Conditions
Operating Temperature
-5..55 °C
Vibration
Random: 0.5Grms @ 5~500 Hz
Shock
HDD: 20G, half sine, 11ms
Standards and Certifications
Certifications
CE, FCC Class A
Dimensions
Net Weight
1.1 kg
Gross Weight
2.02 kg
