Network Digital Signage Player, Support Intel 6 Gen LGA socket type Processor, up to 32Gb DDR4, 3xHDMI, 2xGb LAN, 6xUSB 3.0, 4xCOM, Audio, 2.5" HDD bay, SIM Slot, 1xMini-PCIe, 96W AC Adapter
NDiS-B535
NEXCOM
SKU: 07106600
Price on request
Available on order
Available on order
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
Desktop
Type
Fanless
CPU
Socket
LGA1151
CPU Support Type
Core i3, Core i5, Core i7
Chipset
Chipset
Intel 100 Series
Memory
Form-factor
DDR4
Socket Type
2xSODIMM
ECC
No
Maximum Memory
32 GB
Assembly
Removable
Graphic
Graphic Controller
Intel HD 530 graphics
Ethernet
Controller Type
Intel i219-V 10/100/1000 Mbps
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
4
RS-232
4
USB Total
6
USB v3.x
6
Audio
Audio Controller
Intel HD Audio
Storage Cage
Number Of Cage External
1
2.5" Cage Intenal
1
Extension Slots
Total
1
M.2
1
Mini-PCIe/Mini Card
1
SIM Card slots
1
Connectors
Connectors
4xDB9, 2xRJ45 Ethernet, 6xUSB, Line In, Line Out, DC Input, 3xHDMI
System Power Input
Input Voltage DC
12..12 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Output Power
96 W
Software
Operating System Compatibility
Windows 7, Windows 8.1, Windows 10
Dimensions and weight
Width
294 mm
Height
52 mm
Depth
198 mm
Operating Conditions
Operating Temperature
0..40 °C
Standards and Certifications
Certifications
CE, FCC Class A
Dimensions
Net Weight
2 kg
Gross Weight
2.5 kg
