MERA-3110-3L-4MP

MERA-3110-3L-4MP

Arestech
SKU: 57304600
Rugged Fanless Box PC, 9th/8th Intel Core i3/5/7 35W CPU, up to 64GB RAM, VGA, DVI-D, DP, 8xUSB, 6xCOM, GPIO, 3xGbit LAN RJ45, 4xPoE+ M12, 1xFlexible I/O Bracket, 4x2.5" SATA, 2xCFast/mSATA shared byMini-PCIe, 4xSIM, Audio, 9..48VDC, -40..70C
Price on request
Available
Available

Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
Embedded, Desktop, Wall
Type
Fanless
CPU
СPU Generation/Family
Coffee Lake, Coffee Lake Refresh
Socket
LGA1151
CPU Support Type
Core i3, Core i5, Celeron, Core i7, Pentium
Memory
Form-factor
DDR4
Maximum Memory
64 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Controller Type
Intel i210-AT, Intel i219-LM
10/100/1000 Mbit/s
3
Interfaces
COM Total
6
RS-232/422/485
6
USB Total
8
USB 2.0
2
USB v3.x
6
Storage Cage
Number Of Cage External
4
2.5" Cage External
4
Extension Slots
Total
4
Mini-PCIe/Mini Card
4
Connectors
Connectors
6xDB9, DVI-D, DB15 VGA, 8xUSB, Mic In, Line In, Display Port, 7xRJ45 Ethernet
System Power Input
Input Voltage DC
9 V
Software
Operating System Compatibility
Linux OS, Windows 10
Dimensions and weight
Width
241.5 mm
Height
92.6 mm
Depth
230 mm
Operating Conditions
Operating Temperature
-40..60 °C
Standards and Certifications
Certifications
CE, FCC
Dimensions
Net Weight
4 kg
Gross Weight
7 kg
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
Embedded, Desktop, Wall
Type
Fanless
CPU
СPU Generation/Family
Coffee Lake, Coffee Lake Refresh
Socket
LGA1151
CPU Support Type
Core i3, Core i5, Celeron, Core i7, Pentium
Memory
Form-factor
DDR4
Maximum Memory
64 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Controller Type
Intel i210-AT, Intel i219-LM
10/100/1000 Mbit/s
3
Interfaces
COM Total
6
RS-232/422/485
6
USB Total
8
USB 2.0
2
USB v3.x
6
Storage Cage
Number Of Cage External
4
2.5" Cage External
4
Extension Slots
Total
4
Mini-PCIe/Mini Card
4
Connectors
Connectors
6xDB9, DVI-D, DB15 VGA, 8xUSB, Mic In, Line In, Display Port, 7xRJ45 Ethernet
System Power Input
Input Voltage DC
9 V
Software
Operating System Compatibility
Linux OS, Windows 10
Dimensions and weight
Width
241.5 mm
Height
92.6 mm
Depth
230 mm
Operating Conditions
Operating Temperature
-40..60 °C
Standards and Certifications
Certifications
CE, FCC
Dimensions
Net Weight
4 kg
Gross Weight
7 kg
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
Embedded, Desktop, Wall
Type
Fanless
CPU
СPU Generation/Family
Coffee Lake, Coffee Lake Refresh
Socket
LGA1151
CPU Support Type
Core i3, Core i5, Celeron, Core i7, Pentium
Memory
Form-factor
DDR4
Maximum Memory
64 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Controller Type
Intel i210-AT, Intel i219-LM
10/100/1000 Mbit/s
3
Interfaces
COM Total
6
RS-232/422/485
6
USB Total
8
USB 2.0
2
USB v3.x
6
Storage Cage
Number Of Cage External
4
2.5" Cage External
4
Extension Slots
Total
4
Mini-PCIe/Mini Card
4
Connectors
Connectors
6xDB9, DVI-D, DB15 VGA, 8xUSB, Mic In, Line In, Display Port, 7xRJ45 Ethernet
System Power Input
Input Voltage DC
9 V
Software
Operating System Compatibility
Linux OS, Windows 10
Dimensions and weight
Width
241.5 mm
Height
92.6 mm
Depth
230 mm
Operating Conditions
Operating Temperature
-40..60 °C
Standards and Certifications
Certifications
CE, FCC
Dimensions
Net Weight
4 kg
Gross Weight
7 kg
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
Embedded, Desktop, Wall
Type
Fanless
CPU
СPU Generation/Family
Coffee Lake, Coffee Lake Refresh
Socket
LGA1151
CPU Support Type
Core i3, Core i5, Celeron, Core i7, Pentium
Memory
Form-factor
DDR4
Maximum Memory
64 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Controller Type
Intel i210-AT, Intel i219-LM
10/100/1000 Mbit/s
3
Interfaces
COM Total
6
RS-232/422/485
6
USB Total
8
USB 2.0
2
USB v3.x
6
Storage Cage
Number Of Cage External
4
2.5" Cage External
4
Extension Slots
Total
4
Mini-PCIe/Mini Card
4
Connectors
Connectors
6xDB9, DVI-D, DB15 VGA, 8xUSB, Mic In, Line In, Display Port, 7xRJ45 Ethernet
System Power Input
Input Voltage DC
9 V
Software
Operating System Compatibility
Linux OS, Windows 10
Dimensions and weight
Width
241.5 mm
Height
92.6 mm
Depth
230 mm
Operating Conditions
Operating Temperature
-40..60 °C
Standards and Certifications
Certifications
CE, FCC
Dimensions
Net Weight
4 kg
Gross Weight
7 kg

Documentation
Mera-3100-Datasheet
Documentation
Mera-3100-Datasheet
Documentation
Mera-3100-Datasheet
Documentation
Mera-3100-Datasheet

Get a Quote

Arestech
SKU: 57304600
MERA-3110-3L-4MP
MERA-3110-3L-4MP
MERA-3110-3L-4MP
