iROBO-40524-23R
Industrial Personal Computer 2U GmbH
SKU: 56621800
19" Industrial Computer, Schnittstellen und Add-on Slots vorne, Intel Core i5-7500 7th Gen. CPU, Intel Q170 Chipset, 4GB DDR4 RAM (max.64GB), 128GB SSD, 2xGbit LAN, 8xUSB, HDMI, DVI-D, VGA, 1xPCIe x16 Gen3, 2xPCIe x4, 3x PCI Slots, 500W PSU
Price on request
Available on order
Available on order
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
19" Rackmount
Height
4 U
CPU
СPU Generation/Family
Skylake, Kaby Lake
Processor Installed
Intel Core i5
Socket
LGA1151
CPU Support Type
Core i3, Core i5, Celeron, Core i7, Pentium
Max CPU frequency
3.4 GHz
Number of CPU
4
Chipset
Chipset
Intel Q170
Memory
Form-factor
DDR4
Socket Type
4xDIMM
Default on Board Memory
4 GB
Maximum Memory
64 GB
Graphic
Interfaces
DVI-D, HDMI, VGA
Ethernet
Controller Type
Intel i210-AT, Intel i219-LM
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
6
RS-232
6
RS-232/422/485
1
USB Total
8
USB 2.0
4
USB v3.x
4
Digital Input-Output
Channels of DIO
8
Drive interfaces
RAID Levels
1, 5, 10
mSATA
1
Storage Cage
3.5" Cage Intenal
2
3.5" Cage External
1
5.25" Cage External
1
Installed drive
Drive Type
SSD
1st Storage Capacity
128 GB
Extension Slots
Total
7
PCI Express x16
2
PCI Express x4
2
PCI
3
Connectors
Connectors
DB9, DVI-D, DB15 VGA, HDMI, PS/2 Keyboard/Mouse, 2xRJ45 Ethernet, 8xUSB, Mic In, Line Out
Power Supply
Output Power
500 W
Input Voltage AC
100..240 V
Dimensions and weight
Width
483 mm
Height
177 mm
Depth
450 mm
Operating Conditions
Operating Temperature
0..50 °C
Dimensions
Gross Weight
20.5 kg
