I-7033D
ICP DAS
SKU: 01028400
3 Channels RTD Input Module w/LED
Price on request
Available
Available
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount, Wall
Display
Display Type
LED Character
Interfaces
RS-485
1
Additional Functions
Watchdog timer type
Hardware, Software
Supported Protocols
Industrial Protocols
DCON slave
Analog Input
Total channels of analog input
3
Number of Bits
16 Bit
Sampling rate
15 Hz
Thermal resistance
Pt100, Pt1000, Ni120
Connectors
Connectors
Screw Terminal
System Power Input
Input Voltage DC
10..30 V
Dimensions and weight
Width
72 mm
Depth
35 mm
Height
123 mm
Operating Conditions
Operating Temperature
-25..75 °C
Standards and Certifications
EMS
IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5
Dimensions
Net Weight
0.35 kg
Gross Weight
0.35 kg
