FA30SB3-210

FA30SB3-210

Winmate
SKU: 56480300
Fanless Embedded System, NXP i.MX6 Dual-Core 1GHz SoC, 1GB LPDDR3 RAM, 16GB eMMC, MicroSD Slot, MicroHDMI, 1xCAN, 1xPoE LAN, 1xRS232, 1xUSB 2.0, 1xMicroUSB OTG, 1x8-bit DIO, 12VDC-in Terminal Block with PSU, -20..60C
Price on request
Available
Available

Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
Desktop, Wall
CPU
Processor Installed
ARM Cortex A9
Max CPU frequency
1 GHz
Memory
Form-factor
DDR3
Default on Board Memory
1 GB
Maximum Memory
2 GB
Ethernet
10/100 Mbit/s
1
Interfaces
USB Total
1
Industrial Interfaces
CAN Port
1
Drive interfaces
MicroSD
1
MicroSDHC
1
Connectors
Connectors
RJ45 Ethernet, Micro HDMI, USB type A
System Power Input
Input Voltage DC
9 V
Software
Operating System Compatibility
Android, Linux OS
Dimensions and weight
Width
224 mm
Height
47 mm
Depth
127 mm
Operating Conditions
Operating Temperature
-20..60 °C
Dimensions
Net Weight
3.2 kg
Gross Weight
4 kg
