eBox-3310MX-C
ICOP
SKU: 66161900
Fanless Box-PC, DM&P Vortex86MX+ 933MHz SoC, 1GB DDR2 RAM, VGA, 1x100Mbit LAN, 3xUSB 2.0, 3xCOM, 1xPS/2, SD Slot, 2.5" Drive Bay, Audio, 8-24VDC-in with 10W Power Adapter
Price on request
Available
Available
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
DIN-Rail mount, Desktop, Wall VESA 100
Type
Fanless
CPU
Processor Installed
Vortex86MX+
Socket
CPU onboard
Max CPU frequency
0.93 GHz
Memory
Form-factor
DDR2
Default on Board Memory
1 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
Integrated in Chipset
Interfaces
VGA
Ethernet
10/100 Mbit/s
1
Interfaces
COM Total
3
USB Total
3
USB 2.0
3
Drive interfaces
SATA 3
1
SD Slots
1
LED / Controls
LED
Power LED, SSD LED
Controls
On/Off
Connectors
Connectors
3xDB9, DB15 VGA, PS/2 Keyboard/Mouse, RJ45 Ethernet, 3xUSB, Mic In, Line Out, DC Input, SD card slot
System Power Input
Input Voltage DC
8 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Output Power
22.5 W
Software
Operating System Compatibility
Windows XP, Windows XP Embedded, Debian 4.0, Debian 5.0, Ubuntu 8.04, Ubuntu 8.10, Ubuntu 9.04, Ubuntu 10.04, Edubuntu 9.04 (Ubuntu 8.10 base), Easy Peasy 8.10, Puppy 4.2.1, Puppy 4.1.2, WattsOS2 Warp30, Windows Embedded CE
Dimensions and weight
Width
115 mm
Height
35 mm
Depth
115 mm
Operating Conditions
Operating Temperature
5..50 °C
Standards and Certifications
Certifications
CE, FCC, VCCI
Dimensions
Net Weight
0.5 kg
Gross Weight
1 kg
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
DIN-Rail mount, Desktop, Wall VESA 100
Type
Fanless
CPU
Processor Installed
Vortex86MX+
Socket
CPU onboard
Max CPU frequency
0.93 GHz
Memory
Form-factor
DDR2
Default on Board Memory
1 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
Integrated in Chipset
Interfaces
VGA
Ethernet
10/100 Mbit/s
1
Interfaces
COM Total
3
USB Total
3
USB 2.0
3
Drive interfaces
SATA 3
1
SD Slots
1
LED / Controls
LED
Power LED, SSD LED
Controls
On/Off
Connectors
Connectors
3xDB9, DB15 VGA, PS/2 Keyboard/Mouse, RJ45 Ethernet, 3xUSB, Mic In, Line Out, DC Input, SD card slot
System Power Input
Input Voltage DC
8 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Output Power
22.5 W
Software
Operating System Compatibility
Windows XP, Windows XP Embedded, Debian 4.0, Debian 5.0, Ubuntu 8.04, Ubuntu 8.10, Ubuntu 9.04, Ubuntu 10.04, Edubuntu 9.04 (Ubuntu 8.10 base), Easy Peasy 8.10, Puppy 4.2.1, Puppy 4.1.2, WattsOS2 Warp30, Windows Embedded CE
Dimensions and weight
Width
115 mm
Height
35 mm
Depth
115 mm
Operating Conditions
Operating Temperature
5..50 °C
Standards and Certifications
Certifications
CE, FCC, VCCI
Dimensions
Net Weight
0.5 kg
Gross Weight
1 kg
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
DIN-Rail mount, Desktop, Wall VESA 100
Type
Fanless
CPU
Processor Installed
Vortex86MX+
Socket
CPU onboard
Max CPU frequency
0.93 GHz
Memory
Form-factor
DDR2
Default on Board Memory
1 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
Integrated in Chipset
Interfaces
VGA
Ethernet
10/100 Mbit/s
1
Interfaces
COM Total
3
USB Total
3
USB 2.0
3
Drive interfaces
SATA 3
1
SD Slots
1
LED / Controls
LED
Power LED, SSD LED
Controls
On/Off
Connectors
Connectors
3xDB9, DB15 VGA, PS/2 Keyboard/Mouse, RJ45 Ethernet, 3xUSB, Mic In, Line Out, DC Input, SD card slot
System Power Input
Input Voltage DC
8 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Output Power
22.5 W
Software
Operating System Compatibility
Windows XP, Windows XP Embedded, Debian 4.0, Debian 5.0, Ubuntu 8.04, Ubuntu 8.10, Ubuntu 9.04, Ubuntu 10.04, Edubuntu 9.04 (Ubuntu 8.10 base), Easy Peasy 8.10, Puppy 4.2.1, Puppy 4.1.2, WattsOS2 Warp30, Windows Embedded CE
Dimensions and weight
Width
115 mm
Height
35 mm
Depth
115 mm
Operating Conditions
Operating Temperature
5..50 °C
Standards and Certifications
Certifications
CE, FCC, VCCI
Dimensions
Net Weight
0.5 kg
Gross Weight
1 kg
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
DIN-Rail mount, Desktop, Wall VESA 100
Type
Fanless
CPU
Processor Installed
Vortex86MX+
Socket
CPU onboard
Max CPU frequency
0.93 GHz
Memory
Form-factor
DDR2
Default on Board Memory
1 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
Integrated in Chipset
Interfaces
VGA
Ethernet
10/100 Mbit/s
1
Interfaces
COM Total
3
USB Total
3
USB 2.0
3
Drive interfaces
SATA 3
1
SD Slots
1
LED / Controls
LED
Power LED, SSD LED
Controls
On/Off
Connectors
Connectors
3xDB9, DB15 VGA, PS/2 Keyboard/Mouse, RJ45 Ethernet, 3xUSB, Mic In, Line Out, DC Input, SD card slot
System Power Input
Input Voltage DC
8 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Output Power
22.5 W
Software
Operating System Compatibility
Windows XP, Windows XP Embedded, Debian 4.0, Debian 5.0, Ubuntu 8.04, Ubuntu 8.10, Ubuntu 9.04, Ubuntu 10.04, Edubuntu 9.04 (Ubuntu 8.10 base), Easy Peasy 8.10, Puppy 4.2.1, Puppy 4.1.2, WattsOS2 Warp30, Windows Embedded CE
Dimensions and weight
Width
115 mm
Height
35 mm
Depth
115 mm
Operating Conditions
Operating Temperature
5..50 °C
Standards and Certifications
Certifications
CE, FCC, VCCI
Dimensions
Net Weight
0.5 kg
Gross Weight
1 kg
Documentation
Documentation
Documentation
Documentation
