CEM843PVG-E3845

AXIOMTEK
SKU: 06980600
EmbeddedCOM Express Type module with Intel Atom E3845 1.91GHz, DDR3L, VGA/DDI/LVDS, Gigabit LAN, 8xUSB 2.0, 1xUSB 3.0, DIO, 2xSATA-300, Audio
Price on request
Available
Available

System Architecture
Form Factor
COM Express Compact
Construction
Type
Fanless
CPU
СPU Generation/Family
Bay Trail
Processor Installed
Intel Atom E3845
Max CPU frequency
1.91 GHz
Chipset
Chipset
Intel Bay Trail-I SoC
Memory
Form-factor
DDR3L
Socket Type
2xSODIMM
Maximum Memory
8 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU, Intel Gen7 graphic engine
Interfaces
LVDS, VGA, DDI
Ethernet
Controller Type
Intel i210AT 10/100/1000 Mbps
Total Ethernet
1
10/100/1000 Mbit/s
1
Interfaces
USB Total
9
USB 2.0
8
USB v3.x
1
Audio
Audio Controller
Intel HD Audio
Extension Slots
PCI Express x1
8
Additional Functions
Watchdog timer type
Hardware
Dimensions and weight
Width
95 mm
Length
95 mm
Operating Conditions
Operating Temperature
-40..85 °C
Standards and Certifications
Certifications
CE
Dimensions
Gross Weight
1 kg
System Architecture
Form Factor
COM Express Compact
Construction
Type
Fanless
CPU
СPU Generation/Family
Bay Trail
Processor Installed
Intel Atom E3845
Max CPU frequency
1.91 GHz
Chipset
Chipset
Intel Bay Trail-I SoC
Memory
Form-factor
DDR3L
Socket Type
2xSODIMM
Maximum Memory
8 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU, Intel Gen7 graphic engine
Interfaces
LVDS, VGA, DDI
Ethernet
Controller Type
Intel i210AT 10/100/1000 Mbps
Total Ethernet
1
10/100/1000 Mbit/s
1
Interfaces
USB Total
9
USB 2.0
8
USB v3.x
1
Audio
Audio Controller
Intel HD Audio
Extension Slots
PCI Express x1
8
Additional Functions
Watchdog timer type
Hardware
Dimensions and weight
Width
95 mm
Length
95 mm
Operating Conditions
Operating Temperature
-40..85 °C
Standards and Certifications
Certifications
CE
Dimensions
Gross Weight
1 kg
System Architecture
Form Factor
COM Express Compact
Construction
Type
Fanless
CPU
СPU Generation/Family
Bay Trail
Processor Installed
Intel Atom E3845
Max CPU frequency
1.91 GHz
Chipset
Chipset
Intel Bay Trail-I SoC
Memory
Form-factor
DDR3L
Socket Type
2xSODIMM
Maximum Memory
8 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU, Intel Gen7 graphic engine
Interfaces
LVDS, VGA, DDI
Ethernet
Controller Type
Intel i210AT 10/100/1000 Mbps
Total Ethernet
1
10/100/1000 Mbit/s
1
Interfaces
USB Total
9
USB 2.0
8
USB v3.x
1
Audio
Audio Controller
Intel HD Audio
Extension Slots
PCI Express x1
8
Additional Functions
Watchdog timer type
Hardware
Dimensions and weight
Width
95 mm
Length
95 mm
Operating Conditions
Operating Temperature
-40..85 °C
Standards and Certifications
Certifications
CE
Dimensions
Gross Weight
1 kg
System Architecture
Form Factor
COM Express Compact
Construction
Type
Fanless
CPU
СPU Generation/Family
Bay Trail
Processor Installed
Intel Atom E3845
Max CPU frequency
1.91 GHz
Chipset
Chipset
Intel Bay Trail-I SoC
Memory
Form-factor
DDR3L
Socket Type
2xSODIMM
Maximum Memory
8 GB
Assembly
Removable
Graphic
Graphic Controller
Integrated in CPU, Intel Gen7 graphic engine
Interfaces
LVDS, VGA, DDI
Ethernet
Controller Type
Intel i210AT 10/100/1000 Mbps
Total Ethernet
1
10/100/1000 Mbit/s
1
Interfaces
USB Total
9
USB 2.0
8
USB v3.x
1
Audio
Audio Controller
Intel HD Audio
Extension Slots
PCI Express x1
8
Additional Functions
Watchdog timer type
Hardware
Dimensions and weight
Width
95 mm
Length
95 mm
Operating Conditions
Operating Temperature
-40..85 °C
Standards and Certifications
Certifications
CE
Dimensions
Gross Weight
1 kg

Documentation
Datasheet CEM843
Documentation
Datasheet CEM843
Documentation
Datasheet CEM843
Documentation
Datasheet CEM843
