Industrial Embedded PC QBiX Jumbo, Support for Intel Core i7/i5/i3 6/7th Gen. CPUs, H110 Chipset, 2xDDR4 SO-DIMM, 1xVGA, 1xHDMI, 6xGbit LAN, 8xUSB, 4xCOM, 2.5" HDD bay, M.2 2242/2280 SATA Key B/M, mSATA, GPIO, Terminal Block DC-In (+12V/+19V/+24V)
QBiX-JWB-SKYB110H-A1
GIGAIPC
SKU: 57044500
Price on request
Available on order
Available on order
CPU
Socket
LGA1151
CPU Support Type
Core i3, Core i5, Core i7
Memory
Form-factor
DDR4
Maximum Memory
32 GB
Ethernet
Controller Type
Intel i211-AT 10/100/1000 Mbps, Intel i219-V 10/100/1000 Mbps
Total Ethernet
6
10/100/1000 Mbit/s
6
Interfaces
COM Total
6
RS-232/422/485
6
USB Total
8
USB 2.0
4
USB v3.x
4
Drive interfaces
mSATA
1
Storage Cage
Number Of Cage External
1
2.5" Cage Intenal
1
Extension Slots
M.2
1
Connectors
Connectors
6xDB9, HDMI, 6xRJ45 Ethernet, 8xUSB, DC Input, DB9 GPIO
System Power Input
Input Voltage DC
12..24 V
Dimensions and weight
Width
273 mm
Height
91 mm
Depth
203 mm
Operating Conditions
Operating Temperature
0..50 °C
Dimensions
Net Weight
1.2 kg
Gross Weight
2.5 kg
