XGS-6320-8UP4X
Planet
SKU: 57855400
Managed Ethernet Switch Layer 3, 8-Port 10GBASE-T with PoE++, 4-Port 10GBASE-SR/LR SFP+, RAM 2048Mbytes, Flash Memory 128Mbytes, 1xCOM, 100..240 VAC, Operating Temperature 0..50 C
Price on request
Available on order
Available on order
Ethernet
10 Gbit/s
8
10 Gbit SFP+ Ports
4
Switch Properties
MAC Table Size
32000
Packet Buffer Size
32000 kBit
Jumbo Frame Size
10 kB
Supported Protocols
Protocol Layer 3
RIP V1/V2, OSPF
Managment Protocols
SMTP, SNMPv1/v2c/v3, HTTP, LLDP, Syslog, NTP, GVRP, IGMP Snooping v1/v2/v3, IGMP Querier
Security Protocols
SSH, RADIUS, TACACS+
IEEE Standard
IEEE 802.1ad for Q-in-Q tagging, IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3ad for Port Trunk with LACP, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802ae for 10 Gigabit Ethernet, IEEE 802.3bz for 2.5GBaseX, IEEE 802.3bt for Power over Ethernet
System Power Input
Input Voltage AC
100..240 V
Construction
Mounting Configuration
19" Rackmount
Height
1 U
Dimensions and weight
Width
440 mm
Depth
300 mm
Height
44 mm
Operating Conditions
Operating Temperature
0..50 °C
Humidity
5-95%
Standards and Certifications
Certifications
CE
EMI
FCC Part 15 Subpart B Class A
Dimensions
Net Weight
4.29 kg
Gross Weight
5 kg
Ethernet
10 Gbit/s
8
10 Gbit SFP+ Ports
4
Switch Properties
MAC Table Size
32000
Packet Buffer Size
32000 kBit
Jumbo Frame Size
10 kB
Supported Protocols
Protocol Layer 3
RIP V1/V2, OSPF
Managment Protocols
SMTP, SNMPv1/v2c/v3, HTTP, LLDP, Syslog, NTP, GVRP, IGMP Snooping v1/v2/v3, IGMP Querier
Security Protocols
SSH, RADIUS, TACACS+
IEEE Standard
IEEE 802.1ad for Q-in-Q tagging, IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3ad for Port Trunk with LACP, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802ae for 10 Gigabit Ethernet, IEEE 802.3bz for 2.5GBaseX, IEEE 802.3bt for Power over Ethernet
System Power Input
Input Voltage AC
100..240 V
Construction
Mounting Configuration
19" Rackmount
Height
1 U
Dimensions and weight
Width
440 mm
Depth
300 mm
Height
44 mm
Operating Conditions
Operating Temperature
0..50 °C
Humidity
5-95%
Standards and Certifications
Certifications
CE
EMI
FCC Part 15 Subpart B Class A
Dimensions
Net Weight
4.29 kg
Gross Weight
5 kg
Ethernet
10 Gbit/s
8
10 Gbit SFP+ Ports
4
Switch Properties
MAC Table Size
32000
Packet Buffer Size
32000 kBit
Jumbo Frame Size
10 kB
Supported Protocols
Protocol Layer 3
RIP V1/V2, OSPF
Managment Protocols
SMTP, SNMPv1/v2c/v3, HTTP, LLDP, Syslog, NTP, GVRP, IGMP Snooping v1/v2/v3, IGMP Querier
Security Protocols
SSH, RADIUS, TACACS+
IEEE Standard
IEEE 802.1ad for Q-in-Q tagging, IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3ad for Port Trunk with LACP, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802ae for 10 Gigabit Ethernet, IEEE 802.3bz for 2.5GBaseX, IEEE 802.3bt for Power over Ethernet
System Power Input
Input Voltage AC
100..240 V
Construction
Mounting Configuration
19" Rackmount
Height
1 U
Dimensions and weight
Width
440 mm
Depth
300 mm
Height
44 mm
Operating Conditions
Operating Temperature
0..50 °C
Humidity
5-95%
Standards and Certifications
Certifications
CE
EMI
FCC Part 15 Subpart B Class A
Dimensions
Net Weight
4.29 kg
Gross Weight
5 kg
Ethernet
10 Gbit/s
8
10 Gbit SFP+ Ports
4
Switch Properties
MAC Table Size
32000
Packet Buffer Size
32000 kBit
Jumbo Frame Size
10 kB
Supported Protocols
Protocol Layer 3
RIP V1/V2, OSPF
Managment Protocols
SMTP, SNMPv1/v2c/v3, HTTP, LLDP, Syslog, NTP, GVRP, IGMP Snooping v1/v2/v3, IGMP Querier
Security Protocols
SSH, RADIUS, TACACS+
IEEE Standard
IEEE 802.1ad for Q-in-Q tagging, IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3ad for Port Trunk with LACP, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802ae for 10 Gigabit Ethernet, IEEE 802.3bz for 2.5GBaseX, IEEE 802.3bt for Power over Ethernet
System Power Input
Input Voltage AC
100..240 V
Construction
Mounting Configuration
19" Rackmount
Height
1 U
Dimensions and weight
Width
440 mm
Depth
300 mm
Height
44 mm
Operating Conditions
Operating Temperature
0..50 °C
Humidity
5-95%
Standards and Certifications
Certifications
CE
EMI
FCC Part 15 Subpart B Class A
Dimensions
Net Weight
4.29 kg
Gross Weight
5 kg
