IS-DG308-2F
ISON
SKU: 56339700
Industrial 8-port DIN-Rail Unmanaged Ethernet Switch with 6x 1000 Base-TX ports and 2 100/1000 FX SFP Slot, +12...+58VDC-in, -40..+75 C operating temperature, Dual DC Power Input
Price on request
Available on order
Available on order
Ethernet
Total Ethernet
8
10/100/1000 Mbit/s
6
SFP 100/1000 Mbit Ports
2
Supported Protocols
Managment Protocols
UDP, TCP, ICMP
IEEE Standard
IEEE 802.3 for 10BaseT, IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3x for Flow Control
System Power Input
Input Voltage DC
46..57 V
Construction
Construction Chassis
Aluminium Chassis
Mounting Configuration
DIN-Rail mount, Desktop, Wall
Protection Level of Chassis
IP30
Dimensions and weight
Width
36 mm
Depth
105 mm
Height
142 mm
Operating Conditions
Operating Temperature
-40..75 °C
Standards and Certifications
Certifications
CE, FCC
EMI
EN 55022 Class A
EMS
IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6
Vibration And Shock
IEC 60068-2-6, IEC 60068-2-27
Dimensions
Net Weight
1 kg
Gross Weight
1.5 kg
