GD-4500D-2G

GD-4500D-2G

ICP DAS
SKU: 06254900
Mini-Programmable 80MHz Industrial Controller, 512kb Flash, 512kb SRAM, 2xRS232, 1xRS485, GPRS/GSM, Ethernet, MiniOS7, LCD Display, plastic case
End-of-life product

Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount, Wall
Display
Display Type
STN Dot Matrix LCD
Maximum resolution
128x64 Dots
CPU
Processor Installed
80186
Max CPU frequency
0.08 GHz
Installed drive
Flash Memory Capacity
0.512 MB
EEPROM Memory Capacity
16 kB
Non-volatile NVRAM memory capacity
31 Byte
Drive interfaces
MicroSD
1
Software
Operating System Installed
Mini OS7
Programming Method
C/C++
Analog Input
Total channels of analog input
8
Number of Bits
12 Bit
Sampling rate
1 Hz
Current range
0...20 mA
Digital Input
Total channels of digital input
3
Type
Dry contact, Wet contact
Sink/Source
Source
Level of Logic "0"
0~1 V
Level of Logic "1"
3.5~30 V
Digital Output
Total channels of digital output
3
Type
Open collector
Sink/Source
Sink
Max. load current
100 mA
Output voltage
1~30 V
Ethernet
10/100 Mbit/s
1
Interfaces
COM Total
3
RS-232
2
RS-485
1
Antenna characteristics
Cellular interfaces
2G
Additional Functions
Watchdog timer type
Hardware
Dimensions and weight
Width
55 mm
Depth
140 mm
Height
172 mm
System Power Input
Input Voltage DC
10..30 V
Operating Conditions
Operating Temperature
-15..55 °C
Dimensions
Net Weight
0.2 kg
Gross Weight
0.5 kg
