LP-2841M
ICP DAS
SKU: 10876700
PC-compatible 4xCortex-A53 8 up to 1.6GHz Industrial Controller, 2GB DDR3 RAM, 8GB eMMC, 4GB MicroSD, VGA, 4xCOM, 2xEthernet, 2xUSB, Linux kernel 5.4.70, 12-48VDC-in
Price on request
Available on order
Available on order
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
DIN-Rail mount
Protection Level of Chassis
IP30
CPU
Processor Installed
ARM Cortex-A53
Max CPU frequency
1.6 GHz
Memory
Default on Board Memory
2 GB
SRAM
64 kB
Installed drive
Flash Memory Capacity
8000 MB
Drive interfaces
MicroSD
1
Expansion Module
Quantity of Slots
1
Supported Module
XV - board
Software
Operating System Installed
Linux OS
Programming Method
C/C++
Development Software
GNU C
Ethernet
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
4
RS-232
2
RS-485
2
USB Total
2
Additional Functions
Watchdog timer type
Hardware, Software
Graphic
Interfaces
VGA
Dimensions and weight
Width
35 mm
Depth
167 mm
Height
119 mm
System Power Input
Input Voltage DC
12..48 V
Operating Conditions
Operating Temperature
-25..75 °C
Humidity
10-95%
Dimensions
Gross Weight
1 kg
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
DIN-Rail mount
Protection Level of Chassis
IP30
CPU
Processor Installed
ARM Cortex-A53
Max CPU frequency
1.6 GHz
Memory
Default on Board Memory
2 GB
SRAM
64 kB
Installed drive
Flash Memory Capacity
8000 MB
Drive interfaces
MicroSD
1
Expansion Module
Quantity of Slots
1
Supported Module
XV - board
Software
Operating System Installed
Linux OS
Programming Method
C/C++
Development Software
GNU C
Ethernet
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
4
RS-232
2
RS-485
2
USB Total
2
Additional Functions
Watchdog timer type
Hardware, Software
Graphic
Interfaces
VGA
Dimensions and weight
Width
35 mm
Depth
167 mm
Height
119 mm
System Power Input
Input Voltage DC
12..48 V
Operating Conditions
Operating Temperature
-25..75 °C
Humidity
10-95%
Dimensions
Gross Weight
1 kg
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
DIN-Rail mount
Protection Level of Chassis
IP30
CPU
Processor Installed
ARM Cortex-A53
Max CPU frequency
1.6 GHz
Memory
Default on Board Memory
2 GB
SRAM
64 kB
Installed drive
Flash Memory Capacity
8000 MB
Drive interfaces
MicroSD
1
Expansion Module
Quantity of Slots
1
Supported Module
XV - board
Software
Operating System Installed
Linux OS
Programming Method
C/C++
Development Software
GNU C
Ethernet
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
4
RS-232
2
RS-485
2
USB Total
2
Additional Functions
Watchdog timer type
Hardware, Software
Graphic
Interfaces
VGA
Dimensions and weight
Width
35 mm
Depth
167 mm
Height
119 mm
System Power Input
Input Voltage DC
12..48 V
Operating Conditions
Operating Temperature
-25..75 °C
Humidity
10-95%
Dimensions
Gross Weight
1 kg
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
DIN-Rail mount
Protection Level of Chassis
IP30
CPU
Processor Installed
ARM Cortex-A53
Max CPU frequency
1.6 GHz
Memory
Default on Board Memory
2 GB
SRAM
64 kB
Installed drive
Flash Memory Capacity
8000 MB
Drive interfaces
MicroSD
1
Expansion Module
Quantity of Slots
1
Supported Module
XV - board
Software
Operating System Installed
Linux OS
Programming Method
C/C++
Development Software
GNU C
Ethernet
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
4
RS-232
2
RS-485
2
USB Total
2
Additional Functions
Watchdog timer type
Hardware, Software
Graphic
Interfaces
VGA
Dimensions and weight
Width
35 mm
Depth
167 mm
Height
119 mm
System Power Input
Input Voltage DC
12..48 V
Operating Conditions
Operating Temperature
-25..75 °C
Humidity
10-95%
Dimensions
Gross Weight
1 kg
