DAQ-2501
ADLink
SKU: 02017300
Multifunction PCI Adapter, 8SE 14 bit ADC, FIFO, 4 DAC, 24DI/O, 2 Timers
Price on request
Available
Available
System Architecture
System Bus
Universal PCI
Analog Input
Total channels of analog input
8
Single-Ended channels
8
Number of Bits
14 Bit
Sampling rate
400 Hz
Voltage range
+/-10 V, 0...10 V
Analog Output
Channels of analog input
4
Voltage range
0...10 V, +/-10 V
Digital Input-Output
Channels of DIO
24
Digital Input
Number of channels
2
Counter capacity
16 Bit
Max frequency
40 kHz
Signal Type
Frequency
Connectors
Connectors
68-pin SCSI VHDCI
Software
Operating System Compatibility
Windows XP, Windows 7, Linux OS
Development Software
LabVIEW, Visual Studio .NET, MATLAB, AD-Logger, DAQBench
Operating Conditions
Operating Temperature
0..55 °C
Dimensions
Net Weight
0.36 kg
Gross Weight
0.93 kg
