I/O X Series Expansion Boards

X702

X702

SKU: 02981500

2 Axis Encoder Input Module for I-7188XB/XG/EX/EG

Price on request

Construction

Construction Chassis

Open Frame

Mounting Configuration

Embedded

Digital Input

Number of channels

2

Signal Type

CW/CCW, Pulse/Dir, Quadrant

Counter capacity

32 Bit

Max frequency

1 kHz

Dimensions

Net Weight

0.02 kg

Gross Weight

0.05 kg

Construction
