WTP-8J66-15
Industrial Panel PC with Intel Quad Core CPU, max. 32 GB DDR4 RAM, 15'' XGA Touchscreen, 3x M.2 Expansion Slots
By combining an Intel processor from the "Elkhart Lake" generation with a fully IP66/67/69K-certified housing, the WTP-8J66-15 positions itself as a flexibly deployable fanless panel PC that offers numerous possibilities for peripheral connection, interface customization, and system optimization.
The Intel Celeron J6412 is an AMD64 quad-core CPU from the embedded PC segment that delivers clock speeds of up to 2.60 GHz during peak loads while operating at only 10 watts TDP. For temporary and permanent storage, the WTP-8J66-15 uses up to 32 GB of DDR4 RAM on two modules in dual-channel mode, an M.2 M-Key SSD as the primary boot medium, and optionally an additional HDD/SSD drive in a 2.5'' drive bay. Despite its compact 15'' format, the WTP-8J66-15 offers an above-average number of expansion slots, including PCI Express x1, three M.2 expansion card slots, and a SIM card socket.
The 15'' touchscreen has an XGA resolution of 1024 x 768 pixels and uses the 4:3 aspect ratio, optimized for technical applications and office environments. For additional displays, the WTP-8J66-15 offers analog VGA and HDMI 2.0b outputs and supports up to three connected, cloned, or independent desktops. Additional native interfaces include USB 2.0 and 3.0, serial COM RS232, and Gigabit Ethernet LAN, with the exact number depending on the selected connector type: In addition to waterproof M12 connectors, the manufacturer also offers an optional cable gland for up to five external connections, enabling configurations such as dual LAN or four USB ports.
For operation in industrial or harsh environments, the WTP-8J66-15 runs fanless within a temperature range of 0° Celsius to 50° Celsius and supports customization, for example, via optical bonding with a brightness of 1000 cd/m². Typical application scenarios range from machine and system control in classic production or Industry 4.0 to H2M interfaces in IoT automation, customer terminals, or infotainment systems.
Industrial Panel PC with Intel Quad Core CPU, max. 32 GB DDR4 RAM, 15'' XGA Touchscreen, 3x M.2 Expansion Slots
By combining an Intel processor from the "Elkhart Lake" generation with a fully IP66/67/69K-certified housing, the WTP-8J66-15 positions itself as a flexibly deployable fanless panel PC that offers numerous possibilities for peripheral connection, interface customization, and system optimization.
The Intel Celeron J6412 is an AMD64 quad-core CPU from the embedded PC segment that delivers clock speeds of up to 2.60 GHz during peak loads while operating at only 10 watts TDP. For temporary and permanent storage, the WTP-8J66-15 uses up to 32 GB of DDR4 RAM on two modules in dual-channel mode, an M.2 M-Key SSD as the primary boot medium, and optionally an additional HDD/SSD drive in a 2.5'' drive bay. Despite its compact 15'' format, the WTP-8J66-15 offers an above-average number of expansion slots, including PCI Express x1, three M.2 expansion card slots, and a SIM card socket.
The 15'' touchscreen has an XGA resolution of 1024 x 768 pixels and uses the 4:3 aspect ratio, optimized for technical applications and office environments. For additional displays, the WTP-8J66-15 offers analog VGA and HDMI 2.0b outputs and supports up to three connected, cloned, or independent desktops. Additional native interfaces include USB 2.0 and 3.0, serial COM RS232, and Gigabit Ethernet LAN, with the exact number depending on the selected connector type: In addition to waterproof M12 connectors, the manufacturer also offers an optional cable gland for up to five external connections, enabling configurations such as dual LAN or four USB ports.
For operation in industrial or harsh environments, the WTP-8J66-15 runs fanless within a temperature range of 0° Celsius to 50° Celsius and supports customization, for example, via optical bonding with a brightness of 1000 cd/m². Typical application scenarios range from machine and system control in classic production or Industry 4.0 to H2M interfaces in IoT automation, customer terminals, or infotainment systems.
