Select-Panel-Client-10.1--C

SKU: 80102600
Select Panel Client 10.1" Einbau, IP54 Front, 1280x800, 500cd/m2, PCAP Touch, i.MX 8M Plus Quad-Core SoC, 2GB LPDDR4 RAM, 8GB eMMC, 1xGbE PoE LAN, 1xUSB-C 3.0, 2xUSB 2.0, 48V PoE DC-in, Prime OS
Price on request
Available
Available
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
Mounting Configuration
Panel, Wall VESA 75
Protection Level of Front Side (Panel)
IP54
Protection Level of Chassis
IP20
Type
Fanless
Display
Display Type
LCD TFT
Diagonal
10.1 "
Maximum resolution
1280x800 Dots
Aspect Ratio
16:10
Brightness
500 Cd/m2
Contrast Ratio
900~1
Touch Screen
Touch Screen Type
Capacitive
CPU
Processor Installed
NXP i.MX 8M Plus
Socket
CPU onboard
Max CPU frequency
1.8 GHz
Chipset
Chipset
SoC
Memory
Form-factor
DDR4
Socket Type
Soldered
ECC
No
Default on Board Memory
2 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Total Ethernet
1
PoE+ 10/100/1000 Mbit/s
1
Interfaces
USB Total
3
USB 2.0
2
USB v3.x
1
Installed drive
Drive Type
Flash
Storage Form-Factor
eMMC
1st Storage Capacity
8 GB
Connectors
Connectors
RJ45 Ethernet, 2xUSB, USB type C
System Power Input
Input Voltage DC
48..48 V
Software
Operating System Compatibility
Prime OS
Dimensions and weight
Width
262 mm
Height
180.6 mm
Depth
52 mm
Operating Conditions
Operating Temperature
0..50 °C
Humidity
20-90%
Standards and Certifications
Certifications
CE
Safety
UL
Dimensions
Net Weight
2.6 kg
Gross Weight
3.1 kg
Construction
Construction Chassis
Metal Chassis with Aluminium Heatsink
