PM-1004

PM-1004

IEI
SKU: 55273200
PC/104 4-port RS-232/422/485 Module, 921.6Kbps
End-of-life product

System Architecture
Form Factor
PC/104
Construction
Type
Fanless
Chipset
Chipset
TI 16C554A
Interfaces
COM Total
4
RS-232/422/485
4
Software
Operating System Compatibility
Windows XP, Linux OS, Windows NT, Windows 2000, Windows Embedded CE
Dimensions and weight
Width
96 mm
Length
90 mm
Operating Conditions
Operating Temperature
0..60 °C
Dimensions
Gross Weight
0.5 kg
