PEX-057T-8A
ICOP
SKU: 56408000
5.7" Panel PC, TFT LCD 640x480, 400 cd/m2, Vortex86DX 1GHz CPU, 1GB DDR2, 1xLAN, 1xCOM, 2xUSB, Micro SD, 8-35 VDC
Price on request
Available
Available
Construction
Construction Chassis
Heavy-Duty Steel Chassis
Mounting Configuration
Panel, Wall VESA 75
Protection Level of Front Side (Panel)
IP65
Type
Fanless
Display
Display Type
LCD TFT
Diagonal
5.7 "
Maximum resolution
640x480 Dots
Brightness
400 Cd/m2
Touch Screen
Touch Screen Type
Resistive
CPU
Processor Installed
Vortex86DX
Max CPU frequency
1 GHz
Memory
Form-factor
DDR3
Default on Board Memory
1 GB
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Controller Type
Integrated with Chipset
Total Ethernet
1
10/100 Mbit/s
1
Interfaces
COM Total
1
RS-232/422/485
1
USB Total
2
USB 2.0
2
Drive interfaces
CompactFlash Slots
1
MicroSD
1
Extension Slots
Total
1
Mini-PCIe/Mini Card
1
Additional Functions
Watchdog timer type
Software
LED / Controls
LED
1xOn/Off LED, Power LED
Controls
On/Off
Connectors
Connectors
PS/2 Keyboard/Mouse, RJ45
System Power Input
Input Voltage DC
8..35 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Software
Operating System Compatibility
MS DOS, Windows CE 5.0, Windows CE 6.0, Windows XP, Linux OS
Operating Conditions
Operating Temperature
-20..60 °C
Standards and Certifications
Certifications
CE, FCC, VCCI
Dimensions
Net Weight
0.6 kg
Gross Weight
0.6 kg
