HMI-043T-EM41N-BF02
ICOP
SKU: 07711000
4.3" Fanless HMI Panel PC, WQVGA 480x272, 350 cd/m2, Vortex86EXm 400MHz CPU, 128MB DDR3, 1xLAN, 3xCOM, 2xUSB 2.0, RFID, 8bit GPIO
Price on request
Available
Available
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
Embedded, Panel, Wall
Protection Level of Front Side (Panel)
IP65
Type
Fanless
Display
Display Type
LCD TFT
Diagonal
4.3 "
Maximum resolution
480x272 Dots
Brightness
280 Cd/m2
Contrast Ratio
450~1
Touch Screen
Touch Screen Type
Resistive
CPU
Processor Installed
Vortex86EX
Socket
CPU onboard
Max CPU frequency
0.4 GHz
Chipset
Chipset
Vortex86 System-on-Chip
Memory
Form-factor
DDR3
Socket Type
Soldered
Default on Board Memory
0.13 GB
Assembly
Fixed on Board
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Total Ethernet
1
10/100 Mbit/s
1
Interfaces
COM Total
3
RS-232
1
RS-485
2
USB Total
2
USB 2.0
2
Digital Input-Output
Channels of DIO
8
Drive interfaces
SD Slots
1
Connectors
Connectors
3xDB9, RJ45 Ethernet, 2xUSB, DC Input, SD card slot
System Power Input
Input Voltage DC
5..5 V
Software
Operating System Compatibility
MS DOS, Linux OS, Windows Embedded CE
Dimensions and weight
Width
129.1 mm
Height
95 mm
Depth
13.9 mm
Operating Conditions
Operating Temperature
0..50 °C
Dimensions
Net Weight
2 kg
Gross Weight
2 kg
