GOT-817L-511-R-DC
AXIOMTEK
SKU: 56523700
17" XGA TFT 1280x1024, IP66/IP69K Stainless Steel Fanless with Intel Core i5-7300U 3.5GHz, resistive touchscreen, Up to 16GB 1x260-pin DDR4-2133, 1x2.5" SATA bay, 2xCOM, 4xUSB 2.0, 1xGbe LAN, 2xPCle Mini Card slot, power input 9-36V DC
Price on request
Available
Available
Construction
Construction Chassis
Stainless Steel
Mounting Configuration
Wall VESA 100, Wall VESA 75
Protection Level of Front Side (Panel)
IP66
Protection Level of Chassis
IP66
Type
Fanless
Display
Display Type
LCD TFT
Diagonal
17 "
Maximum resolution
1024x768 Dots
Brightness
350 Cd/m2
Touch Screen
Touch Screen Type
Resistive
CPU
СPU Generation/Family
Kaby Lake
Processor Installed
Intel Core i5-7300U
Max CPU frequency
3.5 GHz
Chipset
Chipset
Intel Kaby Lake SoC
Memory
Form-factor
DDR4
Socket Type
1xSODIMM
Maximum Memory
16 GB
Graphic
Graphic Controller
Integrated in CPU
Ethernet
Total Ethernet
1
10/100/1000 Mbit/s
1
Interfaces
COM Total
2
RS-232/422/485
2
USB Total
4
USB 2.0
4
Storage Cage
Number Of Cage External
1
2.5" Cage Intenal
1
Extension Slots
Total
2
Mini-PCIe/Mini Card
2
Additional Functions
Watchdog timer type
Software
LED / Controls
LED
Power LED
Controls
On/Off, Control Buttons
Connectors
Connectors
2xDB9, RJ45 Ethernet, 4xUSB
Power Supply
Supported Types of Power Supply
External power adapter AC/DC
Software
Operating System Compatibility
Windows 10 IoT Enterprise, Windows 10
Dimensions and weight
Width
615 mm
Height
585 mm
Depth
50 mm
Operating Conditions
Operating Temperature
-20..55 °C
Vibration
1G, 5 ~ 500Hz, random for 2.5" SSD
Standards and Certifications
Certifications
CE
Dimensions
Net Weight
6.2 kg
Gross Weight
9.4 kg
