EMC-0201-ST-WA-M
Antaira Technologies
SKU: 80316000
Industrial Media Converter, IP30, 1x10/100Base-TX, 1x100Base-FX Single Fiber, Multi-Mode 2KM, ST Connector TX1310nm, RX1550nm, 100..240 VAC, Operating Temperature 0..50 C
Price on request
Available
Available
Ethernet
Total Ethernet
2
10/100 Mbit/s
2
Fiber
Number of Optical Ports
1xST
Type of Fibre Optic
multi-mode
Transmission Range
2 km
Length Wave RX
1550 nm
Length Wave TX
1310 nm
Supported Protocols
IEEE Standard
IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X)
Switch Properties
MAC Table Size
2000
Jumbo Frame Size
9 kB
System Power Input
Input Voltage AC
100..240 V
Operating Conditions
Operating Temperature
0..50 °C
Humidity
5-90%
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
Wall, 19" Rackmount
Protection Level of Chassis
IP30
Dimensions and weight
Width
71 mm
Depth
26 mm
Height
94 mm
Standards and Certifications
Certifications
CE, FCC Class A
Dimensions
Net Weight
0.2 kg
Gross Weight
0.45 kg
