EBC-355XP

SKU: 57419000

3.5" Embedded SBC, Intel Atom E3800 CPU, DDR3L SO-DIMM up to 8 GB, 1xVGA, 1xHDMI, 1xLVDS, 2xGbE LAN, 2xSATA2, 4xCOM, 4xUSB, GPIO, Audio, 2xMini PCIe, +12V DC-in

Price on request

System Architecture

Form Factor

3.5"

CPU

СPU Generation/Family

Bay Trail

CPU Support Type

Atom

Memory

Form-factor

DDR3L

Socket Type

1xSODIMM

Maximum Memory

8 GB

Graphic

Graphic Controller

Intel Gen7 graphic engine

Interfaces

HDMI, VGA

Ethernet

Controller Type

Intel i210

Total Ethernet

10/100/1000 Mbit/s

Interfaces

COM Total

RS-232

RS-232/422/485

USB Total

USB 2.0

Audio

Audio Controller

Realtek ALC888

Extension Slots

Total

Mini-PCIe/Mini Card

Additional Functions

Watchdog timer type

Software

Connectors

4xDB9, DB15 VGA, HDMI, 2xRJ45, 4xUSB, Mic In, Line Out, DB15 GPIO

Dimensions and weight

Width

102 mm

Length

146 mm

Operating Conditions

Operating Temperature

-40..85 °C

Standards and Certifications

Certifications

CE, FCC Class A

Dimensions

Gross Weight

0.7 kg
