APL-35-J3455

ICOP
SKU: 09715900
Intel Apollo Lake J3455 CPU Module, DP/eDP, 2xGbE LAN, 5xCOM, 4xUSB 3.0, 2xUSB 2.0, 8bit GPIO, mPCIe, SATA, M.2 (M-key 2242), Audio, 12VDC
Price on request
Available
Available
System Architecture
Form Factor
3.5"
Construction
Type
Fanless
CPU
Processor Installed
Intel Celeron J3455
Max CPU frequency
2.3 GHz
Number of CPU
1
Memory
Form-factor
DDR3L
Socket Type
1xSODIMM
Maximum Memory
8 GB
Assembly
Removable
Graphic
Interfaces
2xDisplayPort
Ethernet
Controller Type
Intel i211-AT 10/100/1000 Mbps
Total Ethernet
2
10/100/1000 Mbit/s
2
Interfaces
COM Total
6
USB Total
6
USB 2.0
2
USB v3.x
4
Audio
Audio Controller
Realtek ALC662
Drive interfaces
MicroSD
1
Extension Slots
SIM Card slots
1
M.2
1
Mini-PCIe/Mini Card
1
Connectors
Internal Ports
SATA 2, 2xUSB 2.0, 6-pin KB/MS, 10-pin GPIO, 5xCOM, 40-pin eDP
Connectors
2xRJ45, 4xUSB, Line Out, DC Input, 2xDisplayPort, RJ45 (COM)
Software
Operating System Compatibility
Linux OS, Windows 10
Dimensions and weight
Width
148 mm
Length
102 mm
Operating Conditions
Operating Temperature
0..60 °C
Dimensions
Gross Weight
0.5 kg
