W10FA3S-IPH1HM

W10FA3S-IPH1HM

Winmate
SKU: 56311100
Fanless Panel PC 10.1" TFT LCD, 1024x600, resistive touch, ARM Cortex A9 iMX6 1.0GHz CPU, 1GB LPDDR3, 16GB eMMC, 1xCOM, 1xUSB 2.0, 1xUSB OTG, 1xLAN (PoE), 1xMicro SD slot, 1xCAN Bus, 12V DC-In
Price on request
Available
Available

Construction
Mounting Configuration
Embedded, Panel, Wall
Protection Level of Chassis
IP65
Display
Display Type
LCD TFT
Diagonal
10.1 "
Maximum resolution
1024x600 Dots
Brightness
200 Cd/m2
Touch Screen
Touch Screen Type
Resistive
CPU
Processor Installed
ARM Cortex A9
Max CPU frequency
1 GHz
Memory
Form-factor
DDR3
ECC
No
Default on Board Memory
1 GB
Maximum Memory
2 GB
Assembly
Fixed on Board
Ethernet
Total Ethernet
1
Interfaces
COM Total
1
RS-232/422/485
1
USB Total
2
USB 2.0
1
Industrial Interfaces
CAN Port
1
Drive interfaces
MicroSD
1
Connectors
Connectors
DB9, RJ45 Ethernet, 2xUSB, MicroSD card slot
System Power Input
Input Voltage DC
12..12 V
Power Consumption
10 W
Software
Operating System Compatibility
Linux OS, Ubuntu
Operating System Installed
Android
Operating Conditions
Operating Temperature
0..50 °C
Standards and Certifications
Certifications
CE, FCC
Dimensions
Net Weight
1.5 kg
Gross Weight
3 kg
