W04FA3S-ELT1

W04FA3S-ELT1

Winmate
SKU: 57937000
4.3" Fanless Panel PC, EL Series, IP65 Front, 480x272, 400 cd/m2, PCAP Touch, NXP i.MX6 Dual Core 1GHz SoC, 1GB LPDDR3 RAM, 8GB eMMC, 1xCOM, 1xUSB 2.0, 1xUSB OTG, 1xGbE LAN, 12-24VDC-in w/PSU
Price on request
Available
Available
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
Panel
Protection Level of Front Side (Panel)
IP65
Type
Fanless
Display
Display Type
LCD TFT
Diagonal
4.3 "
Maximum resolution
480x272 Dots
Brightness
400 Cd/m2
Contrast Ratio
900~1
Touch Screen
Touch Screen Type
Capacitive
CPU
Processor Installed
NXP i.MX6 dual-core
Socket
CPU onboard
Max CPU frequency
1 GHz
Chipset
Chipset
SoC
Memory
Form-factor
DDR3
Socket Type
Soldered
ECC
No
Default on Board Memory
1 GB
Maximum Memory
2 GB
Assembly
Fixed on Board
Ethernet
Total Ethernet
1
10/100/1000 Mbit/s
1
Interfaces
COM Total
1
RS-485
1
USB Total
2
USB 2.0
2
Installed drive
Drive Type
SSD
Storage Form-Factor
eMMC
1st Storage Capacity
8 GB
LED / Controls
LED
1xHDD LED
Controls
1xReset
Connectors
Connectors
DB9, RJ45 Ethernet, 1xUSB, DC input (terminal block), 1xMicro USB, 1xCAN Bus
System Power Input
Input Voltage DC
12..24 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Output Power
50 W
Software
Operating System Compatibility
Linux OS, Ubuntu
Dimensions and weight
Width
387.6 mm
Height
257.7 mm
Depth
52.5 mm
Operating Conditions
Operating Temperature
0..50 °C
Humidity
10-90%
Standards and Certifications
Certifications
CE/FCC
Dimensions
Net Weight
0.3 kg
Gross Weight
0.6 kg
