UPOE-800XG
Planet
SKU: 80263400
Managed Injector Hub, 8x10/100/1000/2.5G/5G/10GBase-T with PoE++, 100..240 VAC, Operating Temperature 0..50C
Price on request
Available
Available
Ethernet
Total Ethernet
8
10 Gbit/s
8
PoE+ 10 Gbit/s
8
Supported Protocols
Managment Protocols
SNMPv1/v2c/v3, HTTP, LLDP, Syslog, NTP, DDNS
Security Protocols
HTTPS, RADIUS
IEEE Standard
IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X), IEEE 802.3bz for 5GBaseT and 2.5GBaseT, IEEE 802.3bt for Power over Ethernet
System Power Input
Input Voltage AC
100..240 V
Dimensions and weight
Width
440 mm
Depth
301 mm
Height
44 mm
Operating Conditions
Operating Temperature
0..50 °C
Humidity
5-90%
Standards and Certifications
Certifications
CE, FCC Class A
Dimensions
Net Weight
3.8 kg
Gross Weight
4.3 kg
