TAP400

TAP400

Teltonika Networks
SKU: 80365000
WI-FI ACCESS POINT, IP30, Wi-Fi 6, Mediatek, Dual-Core, 1.3 GHz, 1x10/100/1000/2500 Mbps, 44..57 VDC, Operating Temperature 0..50 C
Price on request
Available
Available

Ethernet
Total Ethernet
1
2,5 Gbit/s
1
Wi-Fi
Wi-Fi Standard
802.11a/b/g/n/ac, 802.11a/b/g/n/ac/ax
Security
WPA2-Enterprise
Supported Protocols
Managment Protocols
HTTP, UDP, DNS, TCP, ICMP
Security Protocols
HTTPS, SSH, SSL
IEEE Standard
IEEE 802.3 for 10BaseT, IEEE 802.3az for Energy-Efficient Ethernet, IEEE 802.3u for 100BaseT(X)
System Power Input
Input Voltage DC
44..57 V
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
Ceiling mounting
Protection Level of Chassis
IP30
Dimensions and weight
Width
158 mm
Depth
31.4 mm
Operating Conditions
Operating Temperature
0..50 °C
Humidity
10-90%
Standards and Certifications
Certifications
CE, WEEE, FCC, EAC, CB
EMI
EN 61000-3-2, EN 61000-3-3
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-11, EN 55032, EN 55035
Safety
EN 62368-1 (LVD)
Dimensions
Net Weight
0.3 kg
Gross Weight
0.8 kg
Ethernet
Total Ethernet
1
2,5 Gbit/s
1
Wi-Fi
Wi-Fi Standard
802.11a/b/g/n/ac, 802.11a/b/g/n/ac/ax
Security
WPA2-Enterprise
Supported Protocols
Managment Protocols
HTTP, UDP, DNS, TCP, ICMP
Security Protocols
HTTPS, SSH, SSL
IEEE Standard
IEEE 802.3 for 10BaseT, IEEE 802.3az for Energy-Efficient Ethernet, IEEE 802.3u for 100BaseT(X)
System Power Input
Input Voltage DC
44..57 V
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
Ceiling mounting
Protection Level of Chassis
IP30
Dimensions and weight
Width
158 mm
Depth
31.4 mm
Operating Conditions
Operating Temperature
0..50 °C
Humidity
10-90%
Standards and Certifications
Certifications
CE, WEEE, FCC, EAC, CB
EMI
EN 61000-3-2, EN 61000-3-3
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-11, EN 55032, EN 55035
Safety
EN 62368-1 (LVD)
Dimensions
Net Weight
0.3 kg
Gross Weight
0.8 kg
Ethernet
Total Ethernet
1
2,5 Gbit/s
1
Wi-Fi
Wi-Fi Standard
802.11a/b/g/n/ac, 802.11a/b/g/n/ac/ax
Security
WPA2-Enterprise
Supported Protocols
Managment Protocols
HTTP, UDP, DNS, TCP, ICMP
Security Protocols
HTTPS, SSH, SSL
IEEE Standard
IEEE 802.3 for 10BaseT, IEEE 802.3az for Energy-Efficient Ethernet, IEEE 802.3u for 100BaseT(X)
System Power Input
Input Voltage DC
44..57 V
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
Ceiling mounting
Protection Level of Chassis
IP30
Dimensions and weight
Width
158 mm
Depth
31.4 mm
Operating Conditions
Operating Temperature
0..50 °C
Humidity
10-90%
Standards and Certifications
Certifications
CE, WEEE, FCC, EAC, CB
EMI
EN 61000-3-2, EN 61000-3-3
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-11, EN 55032, EN 55035
Safety
EN 62368-1 (LVD)
Dimensions
Net Weight
0.3 kg
Gross Weight
0.8 kg
Ethernet
Total Ethernet
1
2,5 Gbit/s
1
Wi-Fi
Wi-Fi Standard
802.11a/b/g/n/ac, 802.11a/b/g/n/ac/ax
Security
WPA2-Enterprise
Supported Protocols
Managment Protocols
HTTP, UDP, DNS, TCP, ICMP
Security Protocols
HTTPS, SSH, SSL
IEEE Standard
IEEE 802.3 for 10BaseT, IEEE 802.3az for Energy-Efficient Ethernet, IEEE 802.3u for 100BaseT(X)
System Power Input
Input Voltage DC
44..57 V
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
Ceiling mounting
Protection Level of Chassis
IP30
Dimensions and weight
Width
158 mm
Depth
31.4 mm
Operating Conditions
Operating Temperature
0..50 °C
Humidity
10-90%
Standards and Certifications
Certifications
CE, WEEE, FCC, EAC, CB
EMI
EN 61000-3-2, EN 61000-3-3
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-11, EN 55032, EN 55035
Safety
EN 62368-1 (LVD)
Dimensions
Net Weight
0.3 kg
Gross Weight
0.8 kg

Documentation
TAP400-Datasheet.pdf
Documentation
TAP400-Datasheet.pdf
Documentation
TAP400-Datasheet.pdf
Documentation
TAP400-Datasheet.pdf
