PFN-2053
ICP DAS
SKU: 09899200
PROFINET I/O Module (Dry contact Non-Isolated 16-ch DI) (RoHS)
Price on request
Available
Available
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount
Ethernet
10/100 Mbit/s
2
Supported Protocols
Industrial Protocols
PROFINET slave
Digital Input
Total channels of digital input
16
Type
Dry contact
Sink/Source
Dry: Source
Connectors
Connectors
Screw Terminal
System Power Input
Input Voltage DC
10..30 V
Dimensions and weight
Width
33 mm
Depth
107 mm
Height
126 mm
Operating Conditions
Operating Temperature
-25..75 °C
Dimensions
Gross Weight
0.3 kg
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount
Ethernet
10/100 Mbit/s
2
Supported Protocols
Industrial Protocols
PROFINET slave
Digital Input
Total channels of digital input
16
Type
Dry contact
Sink/Source
Dry: Source
Connectors
Connectors
Screw Terminal
System Power Input
Input Voltage DC
10..30 V
Dimensions and weight
Width
33 mm
Depth
107 mm
Height
126 mm
Operating Conditions
Operating Temperature
-25..75 °C
Dimensions
Gross Weight
0.3 kg
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount
Ethernet
10/100 Mbit/s
2
Supported Protocols
Industrial Protocols
PROFINET slave
Digital Input
Total channels of digital input
16
Type
Dry contact
Sink/Source
Dry: Source
Connectors
Connectors
Screw Terminal
System Power Input
Input Voltage DC
10..30 V
Dimensions and weight
Width
33 mm
Depth
107 mm
Height
126 mm
Operating Conditions
Operating Temperature
-25..75 °C
Dimensions
Gross Weight
0.3 kg
Construction
Construction Chassis
Plastic Chassis
Mounting Configuration
DIN-Rail mount
Ethernet
10/100 Mbit/s
2
Supported Protocols
Industrial Protocols
PROFINET slave
Digital Input
Total channels of digital input
16
Type
Dry contact
Sink/Source
Dry: Source
Connectors
Connectors
Screw Terminal
System Power Input
Input Voltage DC
10..30 V
Dimensions and weight
Width
33 mm
Depth
107 mm
Height
126 mm
Operating Conditions
Operating Temperature
-25..75 °C
Dimensions
Gross Weight
0.3 kg
Documentation
Documentation
Documentation
Documentation
Get a Quote
