Industrial 18.5" TFT LCD Monitor, 1920x1080, P-Cap touch, VGA, HDMI, DP, USB 3.2, 9-36VDC-in
DM2-W185KL
IEI
SKU: 11306300
Price on request
Available on order
Available on order
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
Panel, Wall VESA 100
Protection Level of Front Side (Panel)
IP65
Display
Display Type
LCD
Diagonal
18.5 "
Maximum resolution
1920x1080 Dots
Aspect Ratio
16:9
Brightness
350 Cd/m2
Contrast Ratio
1200~1
Input Interface
DisplayPort, HDMI, VGA
Touch Screen
Touch Screen Type
Capacitive
LED / Controls
LED
Power LED
Controls
On/Off
Connectors
Connectors
DB15 VGA, HDMI, 1xUSB, Line Out, Display Port
System Power Input
Input Voltage DC
9..36 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Operating Conditions
Operating Temperature
-20..60 °C
Humidity
10-95%
Dimensions and weight
Width
458.4 mm
Height
288.8 mm
Depth
50.5 mm
Dimensions
Net Weight
4 kg
Gross Weight
5 kg
