DM2-W156KL
IEI
SKU: 11305700
Industrial 15.6" TFT LCD Monitor, 1920x1080, P-Cap touch, VGA, HDMI, DP, USB 3.2, 9-36VDC-in
Price on request
Available
Available
Construction
Construction Chassis
Metal Chassis
Mounting Configuration
Panel, Wall VESA 100
Protection Level of Front Side (Panel)
IP65
Display
Display Type
LCD
Diagonal
15.6 "
Maximum resolution
1920x1080 Dots
Aspect Ratio
16:9
Brightness
450 Cd/m2
Contrast Ratio
800~1
Input Interface
DisplayPort, HDMI, VGA
Touch Screen
Touch Screen Type
Capacitive
LED / Controls
LED
Power LED
Controls
On/Off
Connectors
Connectors
DB15 VGA, HDMI, 1xUSB, Line Out, Display Port
System Power Input
Input Voltage DC
9..36 V
Power Supply
Type of Power Supply
External power adapter AC/DC
Operating Conditions
Operating Temperature
-20..60 °C
Humidity
10-95%
Dimensions and weight
Width
391.5 mm
Height
250 mm
Depth
49.6 mm
Standards and Certifications
Certifications
CE/FCC
Dimensions
Net Weight
2 kg
Gross Weight
3 kg
